StarTech.com DS52000 Unmanaged 2.5G Switch - 5 DS52000

2.5G switch | Multi-Gigabit | 5 port | Unmanaged | Cat5e/Cat6/Cat6a cabling | Wall mount kit | K-slotThe unmanaged network switch offers five multi-speed Ethernet ports (10/100/1000/2500 Mbps) in a compact and durable all-metal casing while remaining silent and energy-efficient (IEEE 802.3az). The network switch is the ideal solution to dramatically speed up your network to support 2.5GBASE-T, and being an unmanaged switch, you can set it up in no time.Enhance your networkThis network switch allows you to use existing Cat5e/Cat6/Cat6a cabling to increase the bandwidth to 2.5 Gbps, ideal for large file transfers, streaming, network sharing/storage, or other bandwidth-intensive applications. Auto-negotiation detects the highest supported speeds on your devices for maximum performance and compatibility. You can also use it in combination with Wi-Fi 6 (802.11ax) wireless access points to expand your network range, bandwidth, and accessibility.Secure and versatileThe 2.5G switch offers a security K-slot for more permanent and secure setups (cable not included). The unintrusive design and small dimensions (6.1x4.7x1.1 inch / 155x120x30 mm) make it easily adaptable to any deployment and has clear diagnostic LEDs that show the status of the devices at a glance. Additional features such as 9K jumbo frames, full-duplex, 16K MAC address table, QoS IEEE 802.1p, and wall mounting kit give you the flexibility to use it in a multitude of scenarios.The DS52000 is backed for 2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.The StarTech.com Advantage

Data transmission



Jumbo frames



9000


Jumbo frames support



Yes


Store-and-forward



Yes


Switching capacity



2.5 Gbit/s


Design



Housing material



Steel


LED indicators



Y, Yes


Product colour



Black


Rack mounting



No


Wall mountable



Yes


Logistics data



Harmonized System (HS) code



85176990


Master (outer) case height



29 cm


Master (outer) case length



37 cm


Master (outer) case width



30.5 cm


Products per master (outer) case



10 pc(s)


Management features



Quality of Service (QoS) support



Yes


Switch type



Unmanaged


Network



10G support



No


Auto MDI/MDI-X



Yes


Cable types supported



Cat5e, Cat6, Cat6a


Copper ethernet cabling technology



10BASE-T, 1000BASE-TX, 2500BASE-T


Full duplex



Yes


Networking standards



IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 45 �C


Storage temperature (T-T)



-20 - 60 �C


Package dimensions



Depth (package,cm)



13.5 cm


Gross Weight (Package, kg)



0.78 kg


Height (package,cm)



7 cm


Width (package,cm)



28.5 cm


Packaging data



AC adapter included



Yes


Quick start guide



Yes


Wall mounting kit



Yes


Performance



Maximum cable length



100 m


Ports & interfaces



2.5G Ethernet (copper) ports quantity



5


Basic switching RJ-45 Ethernet ports quantity



5


Basic switching RJ-45 Ethernet ports type



2.5G Ethernet (100/1000/2500)


Power connector



DC-in jack


Power



AC input voltage



100 - 240 V


Input current



0.5 A


Output current



1 A


Output voltage



12 V


Power plug type



Type M


Power source



AC/DC


Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



0.6 kg


Product Depth



14.5 cm


Product Height



3 cm


Product Width



12 cm


Sustainability



Sustainability certificates



CE, RoHS


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
