AeroCool AEROPGSLUXRGB-550 Luxrgb550M Rgb Modular Pc AEROPGSLUXRGB-550

Featuring a Prism RGB LED design, the LUX RGB PSU powers your system while delivering a vivid stream of colors. Bring your case to life with 13 unique lighting effects that can be controlled via LED control switch. Smart semi-modular design increases ease of installation and offers easier cable management. 80Plus 230V EU Bronze Certified for up to 88%+ efficiency.

Design



Cooling type



Active


Fan diameter



12 cm


Illumination



Yes


Number of fans



1 fan(s)


Product colour



Black


Logistics data



Master (outer) case height



21.5 cm


Master (outer) case length



49.5 cm


Master (outer) case width



25 cm


Products per master (outer) case



5 pc(s)


Other features



Illumination colour



Blue, Green, Red


Package dimensions



Depth (package,cm)



19.5 cm


Gross Weight (Package, kg)



0.65 kg


Height (package,cm)



9.5 cm


Width (package,cm)



23 cm


Packaging data



Manual



Yes


Performance



80 PLUS certification



80 PLUS Bronze


Purpose



PC


Ports & interfaces



ATX power connector (20+4 pin)



Yes


CPU power cable length



55 cm


CPU power connector (4+4 pin)



Yes


Motherboard power cable length



50 cm


Motherboard power connector



20+4 pin ATX


Number of PATA power connectors



2


Number of SATA power connectors



4


PCI Express connector



Yes


PCI Express power cable length



45 cm


PCI Express power connectors (6+2 pin)



1


SATA power cable length



550


Power



AC input frequency



50 - 60 Hz


AC input voltage



200 - 240 V


Combined power (-12V)



3.6 Watt


Combined power (+12V)



504 Watt


Combined power (+3.3V)



100 Watt


Combined power (+5V)



100 Watt


Combined power (+5Vsb)



12.5 Watt


Efficiency



88 %


Input current



4 A


Max output current (-12V)



0.3 A


Max output current (+12V)



42 A


Max output current (+3.3V)



20 A


Max output current (+5V)



20 A


Max output current (+5Vsb)



2.5 A


Total power



550 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Vendor information



Brand Name


AeroCool


Warranty



1 Year(s)
