Moxa NPORT 5230A 5230A Serial Server Rs-422/485 NPORT 5230A

The NPort� 5200A device servers are designed to make serial devices network-ready in an instant and give your PC software direct access to serial devices from anywhere on the network. The NPort� 5200A device servers are ultra lean, ruggedized, and user friendly, making simple and reliable serial to Ethernet solutions possible.

A Greener Serial-to-Ethernet Solution
The Moxa MiiNe is a small but powerful ARM-based serial-to-Ethernet SoC with RAM and Flash embedded. The NPort� 5200A series saves at least 50% on power consumption compared to existing solutions on the market, helping engineers meet the tough environmental compliance challenges found in today�s industrial environments.

Surge-protected Serial, Ethernet, and Power Lines
Surge, which is typically caused by high voltages that result from switching and lightning transients, is a common threat to all electrical devices. Moxa�s leading-edge surge immunity solution, which is applied to the NPort� 5200A�s serial, power, and Ethernet lines, is tested and proven compliant with IEC 61000-4-5. This state-of-the-art surge protection provides a robust serial-to-Ethernet solution that can protect electrical devices from voltage spikes and withstand electrically noisy environmental conditions.

3-step Web-based Configuration
The NPort� 5200A�s 3-step web-based configuration tool is straightforward and user-friendly. The NPort� 5200A�s web console guides users through 3 simple configuration steps that are necessary to activate the serial-to-Ethernet application. With this speedy 3-step web-based configuration, a user only needs to spend an average of 30 seconds to complete the NPort� settings and enable the application, saving a great amount of time and effort.

COM Port Grouping
The NPort� 5200A�s COM Grouping function allows you to create a COM Group and redirect data from it to several physical COM ports on NPort device servers. With COM Grouping, you will be able to control multiple physical serial ports simultaneously by operating only one COM port.

Design



Housing material



Metal


Product colour



Black


Safety



UL 60950-1


Operational conditions



Operating temperature (T-T)



0 - 60 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-40 - 75 �C


Package dimensions



Gross Weight (Package, kg)



0.25 kg


Ports & interfaces



Cabling technology



10/100Base-T(X)


Ethernet LAN (RJ-45) ports



1


Power



Input voltage



12 - 48 V


Product dimensions



Net Weight (Product, kg)



0.19 kg


Protocols



Supported network protocols



ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2, ARP


Technical details



Auto MDI/MDI-X



Yes


Data bits



5, 6, 7, 8


Ethernet LAN data rates



10, 100


Flow control support



Yes


Flow Control type



RTS/CTS, XON/XOFF


Isolation



1.5 kV


Mean time between failures (MTBF)



847750 Hour


RS-232 signals



CTS, DCD, DSR, DTR, GND, RTS, Rx, Tx


RS-422 signals



GND, RxD+, RxD-, TxD+, TxD-


RS-485 signals



Data+, Data-, GND, RxD+, RxD-, TxD+, TxD-


Serial interface type



RS-422/485


Serial ports quantity



2


Stop bits



1, 1.5, 2


Vendor information



Brand Name


Moxa


Warranty



1 Year(s)


Weight & dimensions



Dimensions (WxDxH)



77 x 111 x 26 mm
