Acer TravelMate TMP414RN-53 I31315U 8/256 W11P EDU Intel? Core? I3 I3-1315U Hybr NX.B22EK.00B

Specs




Design


Product type

The sub-category of the product.

Hybrid (2-in-1)


Product colour

The colour e.g. red, blue, green, black, white.

Black


Form factor

The shape or design of the product.

Convertible (Folder)


Stylus pen support




Built-in stylus pen storage




Display


Display diagonal

Size of the display for this product, measured diagonally, usually in inches.

35.6 cm (14")


Display resolution

The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
20 x 1200 pixels


Touchscreen

A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.




HD type

Type of supported High Definition (e.g. Full HD, 4K Ultra HD).

WUXGA


Panel type

IPS


Display technology marketing name

ComfyView


LED backlight

A backlight is a form of illumination used in liquid crystal displays (LCDs). One type of backlight is made by LEDs, which can be either white or RGB (red green blue). White LEDs are used most often in notebooks and desktop screens, and in virtually all mobile LCD screens. RGB LEDs for backlighting are found in high-end color proofing displays such as HP DreamColor LP2480zx monitor or selected HP EliteBook notebooks, as well as newer consumer grade displays such as Dell's Studio series laptops which have an optional RGB LED display.




Native aspect ratio

The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
:10


Processor


Processor manufacturer

The manufacturer that produced the processor.

Intel


Processor family

A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.

Intel® Core™ i3


Processor generation

Intel Core i3-13xxx


Processor model

The model number for the processor in a computer.

i3-1315U


Processor cores

The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).

6


Processor threads

8


Processor boost frequency

The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.

4.5 GHz


Processor frequency

The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform.

3.3 GHz


Performance cores

2


Efficient cores

4


Processor cache
MB


Processor cache type

Smart Cache


Memory


Internal memory

A computer's memory which is directly accessible to the CPU.

8 GB


Internal memory type

The type of internal memory such as RAM, GDDR5.

DDR4-SDRAM


Memory channels

Dual-channel


Storage


Total storage capacity

The total amount of data that can be stored on the device.

256 GB


Storage media

Used for the storage of data e.g. HDD (hard disk drive), SSD (solid-state drive).

SSD


Number of SSDs installed

1


SSD capacity

The Solid State Drive's data storage capacity.

256 GB


SSD interface

The type of interface(s) with which the Solid State Drive is connected to other hardware.

PCI Express 4.0


NVMe

NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices.




Optical drive type

An optical drive uses laser to read optical discs such as CDs, DVDs and Blu-Ray. Some types of optical drive are: CD ROM drive, CR-RW (CD writer) drive, DVD-ROM.




Card reader integrated

A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.




Compatible memory cards

Types of memory cards which can be used with this product.

MicroSD (TransFlash)


Graphics


On-board graphics card

Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.




On-board GPU manufacturer

Intel


Discrete graphics card




On-board graphics card family

Intel Iris Xe Graphics


Audio


Audio system

System used to play music or speech.

DTS Audio Processing


Number of built-in speakers

4


Built-in microphone

Microphone that is found inside the product.




Number of microphones

2


Camera


Front camera

Camera at the front of the product.




Front camera resolution
20 x 1080 pixels


Front camera HD type

Full HD


Video capturing speed

60 fps



Camera


Infrared (IR) camera




Privacy camera




Privacy type

Privacy shutter


Network


Top Wi-Fi standard

Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 6 (802.11ax)


Wi-Fi standards

The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)


Mobile network connection




Wi-Fi band

The frequency bands the product features.

Tri-band (2.4 GHz / 5 GHz / 6 GHz)


Antenna type

Type of antenna, also known an aerial, e.g. external, internal.

2x2


WLAN controller model

Intel Wi-Fi 6E AX211


WLAN controller manufacturer

Intel


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




Ethernet LAN data rates

The different speed levels of the Ethernet LAN connection.
0, 1000, 10000, 100000 Mbit/s


Bluetooth

Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.




Bluetooth version

The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0).

5.1


MIMO




MIMO type

Multi User MIMO


Ports & interfaces


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2


USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

Number of USB 3.0 (3.1 Gen 1) ports with Type-C connector. USB 3.0 (3.1 Gen 1) is USB interface version which supports transfer rate up to 5 Gbit/s (SuperSpeed). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.

2


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

1


HDMI ports quantity

The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.

1


HDMI version

2.1


Thunderbolt 4 ports quantity

2


Intel® Thunderbolt 4




Combo headphone/mic port




SmartCard slot

A smart card, chip card, or integrated circuit card (ICC) is any pocket-sized card with embedded integrated circuits. Smart cards can provide identification, authentication, data storage and application processing. Smart card slots can be found in various electronic devices e.g. thin clients.




Keyboard


Pointing device

Clickpad + Stylus


Numeric keypad

Small, palm-sized, seventeen key section of a computer keyboard, usually on the very far right. The numeric keypad features digits 0 to 9, addition (+), subtraction (-), multiplication (*) and division (/) symbols, a decimal point (.) and Num Lock and Enter keys. Laptop keyboards often do not have a numpad, but may provide numpad input by holding a modifier key (typically labelled "Fn") and operating keys on the standard keyboard.




Keyboard backlit




Software


Operating system installed

Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.

Windows 11 Pro Education


Battery


Battery technology

The type of battery in the device, e.g. nickel–cadmium (NiCd).

Lithium-Ion (Li-Ion)


Battery capacity

56 Wh


Power


AC adapter power

65 W


DC-in jack

The socket/plug where the DC electricity supply connects to the device.




USB Type-C charging port




Security


Cable lock slot

Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.




Cable lock slot type

Kensington


Fingerprint reader

A scanner used to identify a person's fingerprint for security purposes. After a sample is taken, access to a computer or other system is granted if the fingerprint matches the stored sample. A PIN may also be used with the fingerprint sample.




Smart card reader




Trusted Platform Module (TPM)




Certificates


Wi-Fi certified

Wi-Fi is a popular technology to exchange data wirelessly, using radio waves, over a computer network.




Sustainability


Sustainability certificates

ENERGY STAR


Weight & dimensions


Width

The measurement or extent of something from side to side.

319 mm


Depth

The distance from the front to the back of something.

229 mm


Height

The measurement of the product from head to foot or from base to top.
.9 mm


Weight

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

1.49 kg


Packaging content


AC adapter included




Stylus pen
