APC E3SUPS30KHB1 Easy 3S Double-Conversion E3SUPS30KHB1

Battery



Battery technology



Sealed Lead Acid (VRLA)


Battery voltage



240 V


Number of batteries supported



4


Typical backup time at full load



9 min


Design



Certification



CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH


Form factor



Tower


International Protection (IP) code



IP20


Product colour



White


Features



Input current Total Harmonic Distortion (THD)



3 %


Input frequency



45/65 Hz


Input operation voltage (max)



477 V


Input operation voltage (min)



304 V


Input power factor



0.99


Maximum current



55 A


Noise level



63 dB


Number of input phases



3


Number of output phases



3


Output frequency



50/60 Hz


Output operation voltage (max)



415 V


Output operation voltage (min)



380 V


Output power



30000 Watt


Output power capacity



30 kVA


Output voltage Total Harmonic Distortion (THD)



3 %


UPS topology



Double-conversion (Online)


Waveform



Pure sine


Logistics data



Harmonized System (HS) code



85078000


Operational conditions



Non-operating altitude



0 - 15000 m


Operating altitude



0 - 999.9 m


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



-15 - 40 �C


Other features



Output voltage



400 V


Package dimensions



Depth (package,cm)



111.4 cm


Gross Weight (Package, kg)



5.2 kg


Height (package,cm)



164 cm


Width (package,cm)



68.3 cm


Packaging data



Quick installation guide



Yes


Product dimensions



Net Weight (Product, kg)



4 kg


Product Depth



96.9 cm


Product Height



140 cm


Product Width



50 cm


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


APC


Warranty



1 Year(s)
