Apc Smart-Ups SMT3000IC 8X C13 1X C19 Usb Smartconnect 3000Va. Ups Topology: Lin SMT3000IC

APC Smart-UPS SMT3000IC - 8x C13, 1x C19, USB, SmartConnect, 3000VA. UPS topology: Line-Interactive, Output power capacity: 3 kVA, Output power: 2700 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 5.1 min, Typical backup time at half load: 17.2 min. Form factor: Tower, Product colour: Black, Cable length: 1.83 m. Compliance certificates: RoHS, Certification:Stay always online and prevent data loss As soon as the power fails, an APC Smart-UPS immediately supplies emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the free APC PowerChute software, you can even have critical IT hardware shut down automatically and in a controlled manner when the UPS battery is almost empty. This prevents data loss, downtime and physical damage to hardware. Safety In addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use. Battery life With the help of the SmartConnect Ethernet port, you can easily connect the Smart-UPS to your network and you can easily monitor it remotely. This can be done via the secure and freely accessible APC SmartConnect cloud-based web portal or via EcoStruxure It Expert. SmartConnect Out-of-box remote UPS monitoring, free during a 6-month trial period. Using the SmartConnect Ethernet port, you can easily connect the Smart-UPS to your network and monitor it remotely via the secure APC SmartConnect cloud-based web portal*. In addition, the UPS can always be monitored via this port via EcoStruxure IT Expert (SFTWES1-DIGI). * Extend access to SmartConnect via the following licenses:1 year Standard Plan: ERWPMON1-1Y-DIGI 3 years Standard Plan: ERWPMON1-3Y-DIGI 1 year Advanced Plan: ERWPLUS1-1Y-DIGI 3 years Advanced Plan: ERWPLUS1-3Y-DIGI PowerChute By connecting the UPS to a maximum of one server via a USB cable, it can automatically provide it with a shutdown signal during a prolonged power failure and thus still prevent a hard shutdown. This exact moment can be set via the free APC PowerChute Serial Edition software. Network Management Card If you connect the UPS directly to your network via the optional APC Network Management Card (AP9640/AP9641), it can be easily managed remotely via SNMP or our remote management software Ecostruxure IT Expert (SFTWES1-DIGI). You can also automatically send a shutdown signal via the network to multiple physical and/or virtual servers. By means of the APC PowerChute Network Shutdown Software belonging to the network card, it is even possible to differentiate between the shutdown moment and the order in which this happens. Ease of use By means of physical buttons and an LCD screen, it is possible to set and read out the basic functionalities. Extend the lifespan The internal battery cartridge (RBC55) can be easily, safely and independently replaced by the user. This without having to switch off the APC SMT3000IC or connected equipment. This way you can easily and cheaply extend the life of the APC Smart-UPS and your equipment always stays online. Warranty extension The factory warranty of the SMT3000IC is 3 years, with the exception of the battery cartridge, which has a factory warranty of 2 years. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-04). Switched Outlet Groups: Remote reboot and phased start-up Thanks to the Switched Outlet Groups it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which can limit oversizing of the UPS. It is also possible to reset a group of multiple UPS outlets and the equipment connected to them. If SmartConnect Advanced (ERWPLUS1-1Y-DIGI), a UPS with SmartConnect port + Ecostruxure IT Expert (SFTWES1-DIGI) or a network card (ap9640) in combination with Ecostruxure IT Expert (SFTWES1-DIGI) are used, this can even be done remotely. This APC Smart-UPS is designed for IT professionals or network administrators to maintain
Interfaces/Ports

Network (RJ-45)Yes

Miscellaneous

Environmentally FriendlyYes
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Restriction of Hazardous Substances (RoHS)

Battery Information

Battery ChemistryLead Acid
Hot SwappableYes
Backup/Run Time (Full Load)5.10 Minute
Typical Battery Recharge Time3 Hour

Physical Characteristics

Weight (Approximate)52.50 kg
Form FactorTower
Height435 mm
Width197 mm
Depth544 mm
Product ColorBlack
Color FamilyBlack

Power Description

Input Voltage230 V AC
Output Voltage240 V AC
230 V AC
Waveform TypeSine Wave
Input Voltage Range160 V AC - 286 V AC
Load Capacity (VA)3 kVA
Load Capacity (Watt)2.70 kW


General Information

Product TypeLine-interactive UPS
Manufacturer Part NumberSMT3000IC
schneider-electric
ManufacturerSchneider Electric SA
Product NameSmart-UPS 3kVA Tower UPS
Product LineSmart-UPS
Product SeriesSMT
Brand NameAPC by Schneider Electric

Technical Information

Receptacle TypeIEC Jumper
IEC 60320 C19
IEC 60320 C13
Number of Battery & Surge Outlets11
Transfer Time10 ms
Receptacle Detail8 x IEC 60320 C13
2 x IEC Jumper
1 x IEC 60320 C19
