Asus 90IG06T0-MU9100 Tuf Gaming Ax5400 Wireless 90IG06T0-MU9100

TUF Gaming AX5400
TUF Gaming AX5400 is designed to give you stable and fast wireless and wired connections in device-dense environments. It's a router that benefits all your devices, from laptops, smartphones, and game consoles right down to all the IoT devices in your home.

4X Capacity. 2X Faster.*
WiFi 6 provides faster wireless speeds with OFDMA, BSS coloring and MU-MIMO technologies, and it also boosts network efficiency, so all your devices get their fair share of WiFi bandwidth. It's perfect for busy networks with lots of different WiFi devices, such as laptops, smartphones and smart home devices.
*The data compares speed of 4X4 WiFi 6 solution on 5GHz band 160MHz channel to speed of 4X4 WiFi 5 solution on 5GHz band 80MHz channel

True Multi-Gigabit Wired Speeds
For true multi-gigabit performance, you need both WAN and LAN connections that support these speeds. TUF Gaming AX5400 features both WAN and LAN aggregation, so you can enjoy 2 Gbps wired speeds from your modem all the way to your PC or NAS.

WiFi that Goes Further
We've designed TUF Gaming AX5400 to give you the widest possible WiFi coverage. It uses OFDMA, a new technology in WiFi 6 that allows signals to travel further than they can in WiFi 5. With a 4x4 MIMO configuration and separate 2.4 GHz and 5GHz antennas to reduce interference, along with other enhancements like beamforming, which focuses the signal towards each device, TUF Gaming AX5400 reaches every corner.

Flexible and Scalable Wireless Mesh Networking
If you need more coverage or new functions, you can simply add another compatible router to your AiMesh network at any time!

Stable and Durable
TUF Gaming AX5400 is engineered to deliver maximum WiFi performance. The vent location and double heatsink design improve cooling for increased stability, and the fixed antennas and metal port protectors increase physical durability.

One Router. Three Modes. All Game Types.
TUF Gaming AX5400 provides gamers with different features for different game types.

Switch Modes for an Easy Life
Optimize whatever you're doing with different modes, and boost the task at hand!

Simultaneous Gaming and VPN
VPN Fusion lets you run both a VPN and an ordinary internet connection - simultaneously! So even if other network users need to use a VPN, you can still enjoy maximum gaming speeds.

Commercial-Grade
Security for Your Home
Home network security is crucial when you have multiple connected devices, and even more so when there are devices without anti-virus capabilities such as IoT devices. TUF Gaming AX5400 includes lifetime free AiProtection Pro, including the latest WPA3 security protocol and advanced Parental Controls. Every device is protected with TUF Gaming AX5400, and you can keep an eye on everything that's happening on your network via the handy mobile app.

More Privacy, Anywhere
Instant Guard gives you one-click secure internet access via TUF Gaming AX5400 from anywhere in the world, thanks to its encrypted data-tunneling VPN technology. With TUF Gaming AX5400, you can take your home network with you wherever you go � and say goodbye to web-based third-party VPNs!

Antenna



Antenna design



External


Antennas quantity



6


Design



LED indicators



LAN, Power, WAN, WLAN


Product colour



Black


Product type



Tabletop router


Features



Built-in processor



Yes


Flash memory



256 MB


Internal memory



512 MB


Processor cores



3


Processor frequency



1500 MHz


Works with Amazon Alexa



Yes


Logistics data



Harmonized System (HS) code



85176990


Management features



Bandwidth control



Yes


MIMO



Yes


MU-MIMO technology



Yes


Quality of Service (QoS) support



Yes


Reset button



Yes


Wake-on-LAN ready



Yes


Web-based management



Yes


WPS push button



Yes


Mobile network



3G



No


4G



No


5G



No


Mobile network generation



5G


Network



Built-in FTP server



Yes


Dynamic DNS (DDNS)



Yes


Ethernet LAN



Yes


Ethernet LAN interface type



Gigabit Ethernet


Media server



Yes


Number of guest networks (2.4 GHz)



3


Number of guest networks (5 GHz)



3


Port forwarding



Yes


Port triggering



Yes


VPN server



IPSec, OVPN, PPTP


Operational conditions



Operating relative humidity (H-H)



50 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



20 - 90 %


Storage temperature (T-T)



0 - 70 �C


Package dimensions



Gross Weight (Package, kg)



1.17 kg


Packaging content



AC adapter included



Yes


Cables included



LAN (RJ-45)


Quick start guide



Yes


Warranty card



Yes


Packaging data



Number of products included



1 pc(s)


Ports & interfaces



DC-in jack



Yes


Ethernet LAN (RJ-45) ports



4


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



1


USB port



Yes


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Output current



2.5 A


Output voltage



12 V


Power source type



AC


Product dimensions



Net Weight (Product, kg)



0.9 kg


Protocols



DHCP server



Yes


Security



DMZ support



Yes


Filtering



Yes


Firewall



Yes


Guest access



Yes


MAC address filtering



Yes


MAC address table



64 entries


NAT functionality



PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay


Network address translation (NAT)



Yes


Parental control



Yes


Security algorithms



SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-PSK, WPS


System event log



Yes


Vendor information



Brand Name


Asus


Warranty



1 Year(s)


WAN connection



3G/4G USB modem compatibility



Yes


DSL WAN



No


Ethernet WAN



Yes


SIM card slot



No


WAN connection type



RJ-45


Wireless LAN features



Modulation



1024-QAM


Top Wi-Fi standard



Wi-Fi 6 (802.11ax)


Wi-Fi band



Dual-band (2.4 GHz / 5 GHz)


Wi-Fi standards



802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)


WLAN data transfer rate (first band)



574 Mbit/s


WLAN data transfer rate (max)



5378 Mbit/s


WLAN data transfer rate (second band)



4804 Mbit/s
