ASUS RT-BE86U Wireless Router 10 Gigabit Ethernet Dual-Band 2.4 GHz / 5 GHz Blac 90IG08W0-MO9A0V

Transcend WiFi 7, Beyond Performance
Dominate your network with the ultimate performance for those who demand the absolute best, today and tomorrow. ASUS RT-BE86U, the successor to the legacy RT-AX86U, powered by next-level WiFi 7, delivers blazing-fast dual-band 6800 Mbps for your connected living. The RT-BE86U boasts a monster 20G combined network capacity, unlocking cutting-edge 10G network with a 10G WAN/LAN port and up to four 2.5G LAN ports. The new ASUSWRT 5.0 ensures a worry-free network experience from end-to-end and 24/7.

IEEE 802.11be
Beyond Fast WiFi 7
The RT-BE86U boasts dual-band WiFi 7 technology, achieving blazing-fast speeds of 6800 Mbps, ensuring seamless streaming, gaming, and data-intensive tasks. Whether you-re binge-watching your favorite shows or collaborating in a virtual meeting, this router delivers.

Multi-Gig Network
Unlock Next-gen 10G Network
The RT-BE86U comes with a 10G port and four 2.5G ports that combine for up to ultimate 20G WAN and LAN capacity. Advanced network configurations are made easy with Multi-WAN with auto detection, convenient Mobile Tethering backup via USB further and powerful VLAN controls.
G WAN/LAN Port
The RT-BE86U includes one 10G WAN/LAN port, ready for next-gen entertainment or home studios. It also unlocks the ultra-high speed 10G ethernet backhaul for a robust wired network.

Up to four 2.5G LAN Ports
One 2.5G WAN/LAN port and three 2.5G LAN ports for high-speed entertainment, home studios as well as ultra-fast 2.5G ethernet backhaul.

Multi-WAN with Auto Detection
Multi-WAN input support includes a 10G WAN/LAN port and a 2.5G WAN/LAN port for flexible configurations. Hassle-free auto WAN detection streamlines setup.

Dedicated Gaming Port
One 2.5G LAN port is configured as a dedicated gaming port, prioritizing any connected gaming devices for competitive game play.

Powerful VLAN Controls
Simplify home network management by organizing devices into logical groups using VLANs, making it easier to apply specific security rules and manage access.

4G / 5G Mobile Tethering
Stay connected anytime with convenient USB 4G LTE and 5G mobile tethering, even during internet outages or on the go

DESIGN
Legacy Performance, Evolved
The RT-BE86U builds upon the legacy of the RT-AX86U with WiFi 7 technology, delivering superior network performance and exceptional reliability. Equipped with high-power front-end modules, the external antennas eliminate WiFi dead zones while providing consistent coverage in all directions. The 7-stream design enhances throughput and expands coverage while the detachable antennas, allowing you to physically reposition them to better suit your specific needs, including overcoming obstacles such as walls or other interference.

Next-gen Powerhouse
The RT-BE86U boasts a powerful quad-core 2.6 GHz CPU which increases processing power by up to 30%* for lightning-fast responsiveness, accelerated data transfers, and an optimized gaming experience. It can also handle the most demanding networking scenarios, such as 10G connections or advanced network security.
*Compared to RT-AX86U Pro

Cutting-Edge Cooling
The ASUS RT-BE86U features a meticulously crafted heat dissipation design that seamlessly blends with its sleek aesthetics. The strategically placed black heat sink on the front cover not only enhances the router's visual appeal but also ensures optimal cooling performance.

MESH Network
WiFi 7 Powering AiMesh
RT-BE86U harnesses the power of WiFi 7 MLO into next-gen AiMesh technology, delivering wider coverage, a more stable and secure network and a feature-rich network experience - all under one network name for your entire smart home.

Versatile Backhaul Options
Experience lightning-fast speeds even in houses with thick walls. The RT-BE86U boasts one 10G port and four 2.5G ports, ensuring flexible network configurations and ultra-fast wired gaming experience.

Values Beyond Extension
AiMesh goes beyond just extending coverage or seamless roaming. It works with all compatible ASUS routers, offering easy management, advanced security, and smart home features across your entire network.

NETWORK SECURITY
Triple-level Protection
ASUS Network Security deploys a triple-level protection design and commercial-grade cloud database powered by Trend Micro-, safeguarding your network from end-to-end and 24/7. This powerful and advanced security ensures worry-free network experience against ever evolving cyber threats.

One-Tap Security Scan
One-tap router security assessment identifies vulnerabilities in your security settings, helping to prevent malicious activities or connection attempts made by infected devices.

Advanced Parental Controls
Feature-packed family protection empowers you to nurture a balanced digital life for you and your kids, all without subscriptions.

Safe Browsing & AdGuard
Customize protection for individual users or a group of devices with safety filters to secure your online activities. AdGuard DNS offers ad-blocking and privacy protection features to help block ads.

DNS over DLS
DNS over TLS (DoT) brings enhanced privacy and security to your online world by encrypting your DNS (Domain Name System) traffic. The TLS (Transport Layer Security) protocol protects your digital footprint and keeps your online activities safe from eavesdropping and unwanted data interception by advertisers, ISPs, and any potential surveillance.

NETWORK SEGMENTATION
Powerful Network Management via SSID and VLAN
ASUS Guest Network Pro streamlines the process of creating or connecting to dedicated SSIDs or VLAN with advanced features like IoT Device easy setup and instant VPN connection.

Kid-s Network
Create a dedicated SSID just for the kids to easily manage their screen time without needing to configure each device individually.

IoT Network
Set up and manage all your IoT devices under one secure SSID to provide enhanced security with commercial-grade protection.

Guest Portal
A guest login page tailored for small businesses, with easy settings for branding visuals and targeted redirects to engage with customers in different ways.

VPN Network
Connect to your preferred VPN service through a dedicated subnetwork, with a single click.

VPN
Stay Protected Anywhere, Anytime
Secure browsing, data privacy, remote access - extensive ASUS VPN capabilities handle it all. Support versatile VPN protocols, including the cutting-edge WireGguard- for lightning-fast speeds and optimal performance.

VPN Fusion
Connect to multiple encrypted VPN tunnels simultaneously while maintaining the internet access without interruption.

Site-to-site VPN
Connect your business across the world and keep your data encrypted with top-tier VPN server such as Wireguard(r).

GAME BOOST
Supercharge Your Gameplay
RT-BE86U are built to deliver the very best performance for gamers, with the features and tools to help you win every battle, even in crowded multi-device environments.

Specs




WAN connection


Ethernet WAN




DSL WAN

Whether or not the product features a DSL WAN (Wide Area Network) connection option.




SIM card slot

Whether the device features a SIM card slot.




3G/4G USB modem compatibility




WAN connection type

RJ-45


Wireless LAN features


Wi-Fi band

The frequency bands the product features.

Dual-band (2.4 GHz / 5 GHz)


Top Wi-Fi standard

Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 7 (802.11be)


WLAN data transfer rate (max)

5764 Mbit/s


Wi-Fi standards

The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)


WLAN data transfer rate (first band)
32 Mbit/s


WLAN data transfer rate (second band)

5764 Mbit/s


Network


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




Ethernet LAN interface type

The characteristics of the Ethernet LAN interface.
Gigabit Ethernet


Ethernet LAN data rates

The different speed levels of the Ethernet LAN connection.
, 100, 1000, 2500, 10000 Mbit/s


Networking standards

The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n


Port forwarding




Port triggering




Dynamic DNS (DDNS)




Support Samba (storage)




VPN server

VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard


Media server




VPN support

Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark


Ports & interfaces


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

4


USB port

The device features a socket into which a USB cable can be plugged.




USB 2.0 ports quantity

Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.

1


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

1


DC-in jack

The socket/plug where the DC electricity supply connects to the device.




Management features


Web-based management

Using a website/web application to manage something.




Bandwidth control




Quality of Service (QoS) support




Wake-on-LAN ready




Reset button




WPS push button




Intelligent Mesh technology




MU-MIMO technology




Security


Security algorithms

Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.

WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal, WPS


Firewall




Guest access




Parental control





Security


Filtering




MAC address filtering

Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists.




MAC address table

The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.

64 entries


URL filtering




DMZ support




Network address translation (NAT)




NAT functionality

PPTP Pass-Through L2TP Pass-Through IPSec Pass-Through RTSP Pass-Through H.323 Pass-Through SIP Pass-Through PPPoE Relay


Protocols


DHCP server

A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one.




Design


Product colour

The colour e.g. red, blue, green, black, white.

Black


Indication light




LED indicators

LAN, Power, WAN


On/off switch

The button which is pressed to switch the device on or off.




Product type

The sub-category of the product.

Tabletop router


Packaging content


Cables included

LAN (RJ-45)


AC adapter included




Warranty card




Quick start guide

Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.




Packaging content

RT-BE86U WiFi router RJ-45 cable Power adapter Quick Start Guide Warranty card


Antenna


Antenna design

Internal & external


Antennas quantity

4


Features


Built-in processor

Whether or not a processor is built into the device.




Processor frequency

The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time.

2.6 MHz


Processor cores

The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).

4


Internal memory

The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
00 MB


Flash memory

256 MB


Firmware upgradeable




Power


Power source type

What the power source is.

DC


AC input voltage

The voltage of the AC electricity that is inputted into the product.
0 - 240 V


AC input frequency

50/60 Hz


Output voltage
V


Output current

5 A


Weight & dimensions


Width

The measurement or extent of something from side to side.

235 mm


Depth

The distance from the front to the back of something.

90 mm


Height

The measurement of the product from head to foot or from base to top.

316 mm


Weight

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

854 g


Packaging data


Package type

The type of product package e.g. box.

Box
