Asus TUF GAMING A620M-PLUS WIFI Socket Am5/A620/Ddr5/S-Ata 6Gb/S/Micro Atx TUF GAMING A620M-PLUS WIFI

Product Group:

Motherboards



Manufacturer:

ASUS



SKU:
3614


Product Specifications



Product Name:

ASUS TUF GAMING A620M-PLUS WIFI (Socket AM5/A620/DDR5/S-ATA 6Gb/s/Micro ATX)



Web Address:

www.asus.com



Model Number:

TUF GAMING A620M-PLUS WIFI



EAN:

4711387164266



UPC:
7105164260



Package Type:

Retail



Warranty:

3 Years



BIOS:

256 Mb Flash ROM
UEFI AMI BIOS




Chipset:

AMD A620



CPU Interface:

Socket AM5



CPU Support:

https://www.asus.com/motherboards-components/motherboards/tuf-gaming/tuf-gaming-a620m-plus-wifi/helpdesk_qvl_cpu/?model2Name=TUF-GAMING-A620M-PLUS-WIFI



RAM Technology:

DDR5 (Dual Channel)



RAM Slots:

4 x 288-pin



RAM Speeds:

Up to DDR5 6400+ (O.C.)



Max. Memory Support:
8GB



PCI Express 4.0 x16:

1



PCI Express 3.0 x1:

2



S-ATA 6Gb/s Port(s):

4



RAID:

Raid 0/1/10



M.2 Socket(s):

2 x PCIe Gen 4.0 x4



On-Board LAN:

1 x Realtek 2.5Gb Ethernet
TUF LANGuard




Wireless NIC:

Wi-Fi 6



Wireless Technology:

1x1 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Supports 2.4/5GHz frequency band




Bluetooth:

v5.3



On-Board Audio:

Realtek 7.1 Surround Sound High Definition Audio CODEC



On-Board Video:

Processor with integrated graphics is required



Back PS/2 Keyboard/Mouse Port:

1



Back USB 2.0 Port(s):

4



Back USB 3.2 Port(s) Type-A Gen 1:

2



Back HDMI Port(s):

1



Back DisplayPort(s):

2



Back LAN Port(s):

1



Back Audio Jack(s):

3



Back Other Port(s):

1 x Wi-Fi Module



Back Button(s):

1 x BIOS FlashBack



24-pin ATX Power:

1



8-pin ATX Power:

1



USB 2.0 Header(s):

2



USB 3.2 Header(s) Gen 1:

2



COM Port Header(s):

1



Front Panel Audio Connector:

1



S/PDIF Out Header(s):

1



Internal Other Port(s):

3 x Addressable Gen 2 headers
1 x Aura RGB header




Form Factor:

Micro ATX



Product Width:

244mm



Product Length:

244mm



Package Width:

27.5cm



Package Length:

27.7cm



Package Height:

7cm



Gross Weight:

1.41Kg



Special Features:

ASUS TUF GAMING A620M-PLUS WIFI takes all the essential elements of AMD Ryzen 7000-series processors and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming.



Package Contents:

Motherboard
2 x SATA 6Gb/s Cables
1 x ASUS Wi-Fi Moving Antennas
1 x I/O Shield
1 x TUF Gaming Sticker
1 x Screw package for M.2 SSD
1 x TUF Certification Card
1 x User Guide
