ATEN 4-Port USB KM Switch Black CS724KM

The CS724KM is a 4-Port USB KM Switch that enables users to control up to 4 computers with a single keyboard and mouse. Two switches can be daisy-chained to enable control of up to 8 computers from a single console.
1x 4-port USB Boundless KM Switch
4x LIN6-04U1-V1BG USB Cables (USB 2.0-A to USB 2.0-B; 1.8m/6ft)
4x LIN5-0205-21CG Audio Cables (1.8m/6ft)
1x User Instructions

Features


Single USB keyboard and mouse control up to 4 computers


Daisy-chain two CS724KM units to control up to 8 computers with a single keyboard and mouse


Boundless Switching - simply move the mouse cursor across the display border and onto the corresponding display of the target computer to switch the keyboard/mouse operations from one computer to the next


Boundless Switching Configuration Utility1 - an intuitive GUI tool that enables users to customize monitor layouts


Boundless Switching Focus 2 - a window frame to indicate which computer that it currently has the focus


Extended Desktops Boundless Switching up to 16 monitors3


Port selection via front panel pushbutton, keyboard hotkey, mouse cursor, mouse wheel4, and RS-232 commands


Independently switch keyboard/ mouse, USB peripheral, and audio focus via hotkeys


Supports RS-232 serial commands


Supports Windows and Linux operating systems5


No software required6


Bus-powered - no external power adapter required7



Design


Push button

Yes


Product colour

Black


Hot keys

Yes


Housing material

Metal, Plastic


LED indicators

Yes



Weight & dimensions


Height

25 mm


Width

200 mm


Depth

80.6 mm


Weight

899 g



Packaging content


Cables included

Audio (3.5mm), USB


Manual

Yes



Logistics data


Master (outer) case width

300 mm


Master (outer) case height

194 mm


Products per master (outer) case

5 pc(s)


Harmonized System (HS) code

85176200


Master (outer) case length

336 mm


Master (outer) case net weight

4.5 kg


Master (outer) case gross weight

5.73 kg



Operational conditions


Operating temperature (T-T)

0 - 50 �C


Operating relative humidity (H-H)

0 - 80


Storage temperature (T-T)

-20 - 60 �C



Ports & interfaces


Number of computers controlled

4


Keyboard port type

USB


Console ports

3.5mm headphone, RJ-45, USB A


Mouse port type

USB


USB 2?0 Type-B ports quantity

4


DC-in jack

Yes


Console USB ports quantity

2


USB 2?0 Type-A hub ports quantity

2


USB hub

Yes



Performance


Daisy chain

Yes



Power


Power source

DC



Display


Built-in display

No



Packaging data


Package height

173 mm


Package depth

283 mm


Package width

62 mm


Package weight

1.07 kg
