Be Quiet! Light Base 500 LX White Midi Tower BGW86

LIGHT BASE 500 LX WHITE
Core performance and aesthetics
Light Base 500 LX White stands for a clean design and the core values of gaming: performance, accessibility and functionality.

ELEVATED ELEGANCE
Cool design, cooler GPU
The angled fan frame in the side is not only a testament to elegance and functionality but also directs more air towards the GPU – a part that traditionally requires a lot of it. It provides a neat cutout that works as an efficient air intake. For an easy installation of fans, it slides out to the top. Cable management is easier than ever before with a channel that hides your equipment elegantly. If you install additional fans in the bottom, they line up perfectly with the case floor due to a lowered fan bay.

4 PREINSTALLED LIGHT WINGS LX
Wait, how many fans?!
Light Base 500 LX White features 4 preinstalled Light Wings LX fans. The rear fan is a Light Wings LX 120mm White, the fans on the side are Light Wings LX 120mm PWM White fans with reversed fan blades. All fans feature 16 LEDs inside their hub of the impeller, making for an unmistakable ARGB illumination. The reversed fan blades make sure that their pretty side is visible at all times.

SPACIOUS DESIGN
Size matters after all
Light Base 500 LX White might appear compact, but it comes with enough space for a 360mm radiator, an ATX motherboard and graphics cards up to 400mm length. The smart design of the drive bracket features slots for 1 HDD and 2 SSDs at the same time, without impeding the room for cable management behind the motherboard tray.

BUSINESS IN THE FRONT...
... Party in the back!
The motherboard tray fully supports backside connector designs like Asus BTF (Back to Future), MSI Project Zero, and Gigabyte Project Stealth, for a true and cable-free view. To enable backside connector support without giving up a drive slot, the position of the PSU and drive bracket are simply swapped!

YES TO ARGB
Join the light side
For those who appreciate subtle illumination without compromising on performance, the Light Base 500 LX White adds a touch of sophistication to the core design thanks to the included Light Wings LX White fans. An ARGB controller button with predefined lighting effects and colors is integrated into the I/O panel. The preinstalled rear fan and daisy-chained side fans are connected to a 6-way ARGB and PWM hub, leaving 4 free connectors for additional devices.

Specs




Design


Material

The material from which a thing is or can be made e.g. wood, plastic.

Acrylonitrile butadiene styrene (ABS), Glass, Steel


Form factor

The shape or design of the product.

Midi Tower


Type

Characteristics of the device.

PC


Product colour

The colour e.g. red, blue, green, black, white.

White


Supported motherboard form factors

Design of the supported motherboards.

ATX, micro ATX, Mini-ITX


Number of 3.5" bays

A drive bay is a standard-area for adding hardware to a computer. Most drive bays are fixed to the inside of a case, but some can be removed. A 3.5" drive bay is for floppy disks.

1


Number of 2.5" bays

2


Number of expansion slots

7


Side window

A side window is a transparent side (or part of side) in a housing which enables you to see the internal space of the device.




Suitable for

Who can use the product, or what the product can be used for.

Gaming


Illumination

The device has illumination.




Illumination colour

The colour of the illumination, which is the light which allows you to see the display etc. clearly.

Multi


Illumination location

Case fans


Anti-dust filter




Cable management

Description of improved cable management




Reset button




On/off button




RGB control button




LED indicators




Maximum CPU cooler height
.5 cm


Maximum graphics card length

40 cm


Maximum PSU length
cm


Power supply


Power supply included

There is a power supply with this product.




Supported power supply form factors

ATX, PS2


Ports & interfaces


USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

Number of USB 3.1 (3.1 Gen 2) ports with Type-C connector. USB 3.1 (3.1 Gen 2) is USB interface version which supports transfer rate up to 10 Gbit/s (SuperSpeed+). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.

1


USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

2


Combo headphone/mic port




Cooling


Side fans installed

3x 120 mm


Number of side fans supported (max)

3


Side fans diameters supported
0 mm



Cooling


Rear fans installed

1x 120 mm


Number of rear fans supported (max)

1


Rear fans diameters supported
0, 140 mm


Number of top fans supported (max)

3


Top fans diameters supported
0, 140 mm


Number of bottom fans supported (max)

3


Bottom fans diameters supported
0 mm


Fan speed
00 - 1600 RPM


Maximum airflow

51.5 cfm


Maximum air pressure

1.34 mmH2O


Liquid cooling capability




Side radiator sizes supported
0, 240 mm


Rear radiator sizes supported
0 mm


Top radiator sizes supported
0, 240, 280, 360 mm


Pulse-width modulation (PWM) support




Storage


Supported HDD sizes

The size of the hard disk drives which can be used by the device.

2.5, 3.5"


Technical details


Sustainability certificates

Triman


Compliance certificates

CE, Electronic Industries Alliance (EIA), RoHS, UKCA, WEEE


Weight & dimensions


Width

The measurement or extent of something from side to side.

305 mm


Depth

The distance from the front to the back of something.

432 mm


Height

The measurement of the product from head to foot or from base to top.

436 mm


Weight

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
.9 kg


Packaging data


Package width

The distance from one side of the packaging to the other.

388 mm


Package depth

The distance from the front to the back of the packaging.

515 mm


Package height

The distance from the top to the bottom of the packaging.

493 mm


Package weight

Weight of the packaged product.
.6 kg


Other features


Volume

The amount of a substance contained.

49.6 L
