Broadcom
Broadcom BCM95720A2003AC Bcm5720-2P Internal Ethernet BCM95720A2003AC
(No reviews yet)
Write a Review
- UPC:
- 0650861000017
- MPN:
- BCM95720A2003AC
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Designed for today's enterprise and data center environments, Broadcom's NetXtreme� 1G Ethernet Adapters are the ideal solution for multicore servers, delivering full line-rate throughput across all ports.
The BCM5720 PCIe NIC is a 13th-generation 10/100/1000BASE-T and 10/100/1000BASE-X Ethernet LAN controller solution for high-performance server and networking applications. The host interface supports a separate PCI Express function for each LAN interface. The BCM5720 includes I/O Virtualization (IOV) features such as 17 receive and 16 transmit queues, and 17 MSI-X vectors with flexible vector-to-queue association. These IOV features enable the BCM5720 to support the VMWare� NetQueue and Microsoft� VMQ technologies.
The BCM5720 includes a comprehensive set of hardware features that the system may use to implement IEEE 1588 or IEEE 802.1AS-based time synchronization. These hardware features include a high-precision clock, timestamp registers for receive/transmit packets, and programmable trigger inputs and watchdog outputs.
Design
Component for
Server
Internal
Yes
Product colour
Green
Logistics data
Harmonized System (HS) code
85176990
Network
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN data rates
100, 1000
LAN controller
Broadcom BCM5720
Maximum data transfer rate
1000 Mbit/s
Networking standards
IEEE 802.1as, IEEE 802.3ap, IEEE 802.3az
Wake-on-LAN ready
Yes
Package dimensions
Gross Weight (Package, kg)
0.26 kg
Ports & interfaces
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
2
Host interface
PCI Express
Interface
Ethernet
PCI version
2.0
Product dimensions
Net Weight (Product, kg)
0.2 kg
System requirements
Linux operating systems supported
Yes
Other operating systems supported
Yes
Windows operating systems supported
Y, Yes
Vendor information
Brand Name
Broadcom
Warranty
1 Year(s)
