Cisco C9200CX-12P-2X2G-A. Switch Type: Managed. Basic Switching Rj-45 Ethernet P C9200CX-12P-2X2G-A

Cisco C9200CX-12P-2X2G-A. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 14, USB 2.0 ports quantity: 1. MAC address table: 32000 entries, Switching capacity: 34 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting Extend intent-based networking everywhere Cisco?- Catalyst?- 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified. As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey. Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations. With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of Cisco DNA Center, or Meraki cloud monitoring.
Management & Protocols

ManageableYes

Technical Information

FeaturesFanless

Power Description

Power SourcePower Supply
PoE (RJ-45) PortYes

I/O Expansions

Expansion Slot TypeSFP+
Number of SFP+ Slots2
Total Number of Expansion Slots2.0

Miscellaneous

Application/UsageNetwork
Enterprise
Business
Branch Office

Interfaces/Ports

Network (RJ-45)Yes
ModularYes
Uplink PortYes
Total Number of Network Ports12
Port/Expansion Slot Details12 x Gigabit Ethernet Ports PoE+
2 x 10 Gigabit Ethernet Network
2 x 10 Gigabit Ethernet Uplink

Network & Communication

Layer Supported3
Networking StandardsIEEE 802.1ae
IEEE 802.1D
IEEE 802.3ad
IEEE 802.3af
IEEE 802.3an
IEEE 802.3at
IEEE 802.3bz
IEEE 802.3u
IEEE 802.3z
IEEE 802.1p
IEEE 802.1Q
IEEE 802.1s
IEEE 802.1w
IEEE 802.1x
IEEE 802.3
IEEE 802.3ab


Media & Performance

Network Technology1000Base-T GBase-X GBase-T
Ethernet Technology10 Gigabit Ethernet
Gigabit Ethernet
Media Type SupportedTwisted Pair
Optical Fiber

Physical Characteristics

Weight (Approximate)2.99 kg
Form FactorUnder Table
Wall Mountable
Rack-mountable
Compact
Height43.9 mm
Width243.8 mm
Depth269.2 mm

General Information

Product TypeEthernet Switch
Manufacturer Part NumberC9200CX12P2X2GA
Manufacturer Website Addresshttp://www.cisco.com
ManufacturerCisco Systems, Inc
Product ModelC9200CX-12P-2X2G
Product NameCatalyst C9200CX-12P-2X2G Ethernet Switch
Product LineCatalyst
Product Series9200
Brand NameCisco
