Cooler Master Elite 301 White Mini Tower E301-WGNN-S00

EFFORTLESS EFFICIENCY
High in value and attention to detail, Cooler Master-s Elite 301 offers users a cost effective, space conscious
solution to gaming and computing needs. Elite 301 features a large intake grill and 3x 120mm ARGB fans to ensure a smooth, and efficient running system. The fully black coating and included PSU cover allows for clean builds that are visually appealing as well as functional.

Tool-less Intake Panel
Constructed with a substantially large, unrestricted intake grill to ensure that the system runs cool and efficiently. The front panel could be easily removed by magnets, making it easier for daily maintenance.

Unrestricted Air Flow
Pre-installed with 3x 120mm ARGB fans, providing considerable airflow and adds a layer of style to the system.

Large Support, Minimized Footprint-
Despite its compact size, Elite 301 supports up to 365mm graphics cards, 163.5mm CPU Coolers, providing solid potential for future upgrades.

Versatile Cooling Options
Supports up to six fans and 280mm radiator to ensure that performance is not compromised.

Breathable Power Supply Shroud
The PSU cover is ventilated on top of the power supply location, allowing actively cooled units to be installed in multiple orientations, while maintaining support for passively cooled power supplies.

USB Type-C Support
USB Type C port built into the I/O panel allows multi-purpose, streamlined data transmission.

FEATURE HIGHLIGHTS

Tool-less Intake Panel
Constructed with a substantially large, unrestricted intake grill to ensure that the system runs cool and efficiently. The front panel could be easily removed by magnets, making it easier for daily maintenance.

Versatile Cooling Options
Supports up to six fans and 280mm radiator to ensure that performance is not compromised.

Unrestricted Air Flow
Pre-installed with 3x 120mm ARGB fans, providing considerable airflow and adds a layer of style to the system.

Breathable Power Supply Shroud
The PSU cover is ventilated on top of the power supply location, allowing actively cooled units to be installed in multiple orientations, while maintaining support for passively cooled power supplies.

Large Support, Minimized Footprint-
Despite its compact size, Elite 301 supports up to 365mm graphics cards, 163.5mm CPU Coolers, providing solid potential for future upgrades.

USB Type-C Support
USB Type C port built into the I/O panel allows multi-purpose, streamlined data transmission.

Specs




Design


Material

The material from which a thing is or can be made e.g. wood, plastic.

Plastic, Steel, Tempered glass


Form factor

The shape or design of the product.

Mini Tower


Type

Characteristics of the device.

PC


Product colour

The colour e.g. red, blue, green, black, white.

White


Supported motherboard form factors

Design of the supported motherboards.

ITX, micro ATX


Number of 3.5" bays

A drive bay is a standard-area for adding hardware to a computer. Most drive bays are fixed to the inside of a case, but some can be removed. A 3.5" drive bay is for floppy disks.

1


Number of 2.5" bays

1


Number of expansion slots

4


Side window

A side window is a transparent side (or part of side) in a housing which enables you to see the internal space of the device.




Illumination

The device has illumination.




Illumination colour

The colour of the illumination, which is the light which allows you to see the display etc. clearly.

Multi


Illumination location

Case fans


Anti-dust filter




Cable management

Description of improved cable management




Maximum CPU cooler height
.4 cm


Maximum graphics card length

36.5 cm


Maximum PSU length
cm


Power supply


Power supply included

There is a power supply with this product.




Power supply shroud




Supported power supply form factors

ATX


Ports & interfaces


Audio input

The type of audio input that the device requires, and the connection needed.




Audio output

The type of audio output that the device produces, and the connector(s).




USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

1



Ports & interfaces


USB Type-C ports quantity

1


Cooling


Front fans installed

3x 120 mm


Number of front fans supported (max)

3


Front fans diameters supported
0 mm


Number of rear fans supported (max)

1


Rear fans diameters supported
0 mm


Number of top fans supported (max)

2


Top fans diameters supported
0, 140 mm


Front radiator sizes supported
0, 140 mm


Rear radiator sizes supported
0 mm


Top radiator sizes supported
0, 140, 240, 280 mm


Storage


Supported HDD sizes

The size of the hard disk drives which can be used by the device.

2.5, 3.5"


Weight & dimensions


Width

The measurement or extent of something from side to side.
3.5 mm


Depth

The distance from the front to the back of something.

390 mm


Height

The measurement of the product from head to foot or from base to top.

430 mm


Weight

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

5.42 kg


Packaging data


Package width

The distance from one side of the packaging to the other.

266 mm


Package depth

The distance from the front to the back of the packaging.

477 mm


Package height

The distance from the top to the bottom of the packaging.

446 mm


Package weight

Weight of the packaged product.

6.33 kg


Other features


Volume

The amount of a substance contained.

34.13 L
