Cooler Master MCB-D500D-KGNN-S00 Masterbox Td500 Midi Tower MCB-D500D-KGNN-S00

Airflow in an Art Form
The MasterBox TD500 Mesh & MasterBox TD500 Mesh White embody �airflow performance� in an art form. Three pre-installed ARGB fans flood the system with airflow and lighting, demonstrating the unique effect of ARGB through the Crystalline Tempered Glass.

Each element of design is precision-engineered to maximize performance & quality alongside aesthetics, evolving beyond the current limits of lighting and cooling. With advanced technology sculpted into fine art, the MasterBox TD500 Mesh & Mesh White carve their own path to the bleeding edge.

Polygonal Mesh
Crafted from Cooler Master�s Fine Mesh technology, Polygonal Mesh features a three-dimensional contour and simultaneously provides unobstructed airflow and dust filtration.

Crystalline Tempered Glass
A crystalline design spans the edges of the tempered glass side panel, precision-engineered for strength as well as aesthetics, elevating how builds and system lighting interact with the design.

Triple ARGB Fans
Three addressable RGB fans flood the Polygonal Mesh front panel with lighting while providing considerable airflow to the system.

Certified compatible with: ASUS, Gigabyte, MSI, and ASRock motherboards.

Dual 360mm Radiator Support
For enthusiast-grade cooling, two 360mm radiators are supported on the top and front panel to keep the most extreme systems cool.

Versatile Cooling Options
Support for up to seven 120mm fans and 360mm front and top radiator support ensure that performance is not compromised.

Room For Upgrades
Support for up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length provides room for upgrades to stay ahead of the game.

SickleFlow PWM Fans Included
Newly Optimized blade design with updated curve that provides best balance between airflow and static pressure to take the heat away while remain extremely silence.

Cooling



Fan speed



650 - 1800 RPM


Fan speed control



Yes


Front fans diameters supported



120, 140


Front fans installed



3x 120 mm


Front radiator sizes supported



120, 140, 240, 280, 360


Maximum air pressure



2.5 mmH2O


Maximum airflow



62 cfm


Number of front fans supported (max)



3


Number of rear fans supported (max)



1


Number of top fans supported (max)



3


Rear fans diameters supported



120


Rear radiator sizes supported



120


Top fans diameters supported



120, 140


Top radiator sizes supported



120, 240, 360


Design



Anti-dust filter



Yes


Form factor



Midi Tower


Illumination



Yes


Illumination location



Case fans


Material



Mesh, Plastic, Steel, Tempered glass


Maximum CPU cooler height



16.5 cm


Maximum graphics card length



41 cm


Maximum PSU length



18 cm


Number of 2.5" bays



4


Number of 3.5" bays



2


Number of expansion slots



7


Product colour



Black


Side window



Yes


Supported motherboard form factors



ATX, EATX, micro ATX, Mini-ITX, SSI CEB


Type



PC


Other features



Volume



40.14 L


Package dimensions



Depth (package,cm)



52.7 cm


Gross Weight (Package, kg)



9.04 kg


Height (package,cm)



57 cm


Width (package,cm)



29 cm


Packaging data



LED controller



No


Ports & interfaces



Audio input



Y


Audio output



Y


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



2


Power supply



Power supply included



No


Power supply location



Bottom


Supported power supply form factors



ATX


Product dimensions



Net Weight (Product, kg)



6.95 kg


Product Depth



49.3 cm


Product Height



46.9 cm


Product Width



21.7 cm


Storage



HDD/SSD combo cage



Yes


Supported HDD sizes



2.5, 3.5


Vendor information



Brand Name


Cooler Master


Warranty



1 Year(s)
