D-Link
D-Link DMS-1100-10TP 8-Port 2.5G BASE-T PoE and DMS-1100-10TP
(No reviews yet)
Write a Review
- UPC:
- 0790069437168
- MPN:
- DMS-1100-10TP
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The D-Link DMS-1100 Series 2.5 Gigabit Ethernet Smart Managed Switches are a cost-effective 2.5 Gigabit switch series capable of servicing a range of network needs in any type of business. Featuring eight 2.5 Gigabit access ports and two 10 Gigabit SFP+ uplink ports, these switches are ideal for deploying high-performance 802.11ac Wave 2 access points using 2.5 Gigabit connections, while providing 10 Gigabit wire-speed uplinks for optimal bandwidth when accessing the larger local area network.
Seamless Integration and Future Proof
The DMS-1100 switches support IEEE 802.3bz and are fully backwards compatible with 802.3ab Gigabit Ethernet to deliver 2.5 Gigabit speed over commonly deployed Cat 5e cables over distances up to 100 meters.
Driven by the increasing popularity of 802.11ac Wave 2 access points and the emerging trend of 2.5 Gigabit LAN connections, 2.5 Gigabit technology will ultimately replace Gigabit as the standard for Ethernet connectivity. With backwards compatibility for older standards, the DMS-1100 Series can be flawlessly integrated into existing Gigabit Ethernet network infrastructures while simultaneously making networks future-proof for the next generation of 2.5 Gigabit connectivity.
Complete Layer 2 and Troubleshooting Features
The DMS-1100 switches come with a complete lineup of L2 features, including port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The switches also feature loopback detection and cable diagnostics to help network administrators identify and solve network problems quickly and easily. Loopback detection is used to detect loops created by a specific port and automatically shuts down the affected port. Cable diagnostics helps network administrators quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.
Versatile Management
The DMS-1100 switches support a variety of management options. An intuitive, web-based Graphical User Interface (GUI) enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.
These switches also come with the D-Link Network Assistant (DNA) utility that simplifies the configuration of devices supporting the D-Link Discovery Protocol. This utility allows network administrators to discover multiple D-Link Smart Managed Switches within the same L2 network segment and displays them on screen for instant access. With this utility, users do not need to change the IP address of their PC. It further allows for simultaneous configuration and basic setup of all discovered devices, including password changes and firmware upgrades.
The DMS-1100 Series also supports D-View. D-View is a network management system that allows for the central management of critical network characteristics such as availability, reliability, resilience, and security.
Power over Ethernet Support
The DMS-1100-10TP supports industry standard IEEE 802.3at power over Ethernet across all eight copper ports. It features a total power budget of 240 W, capable of supplying up to 30 W of power per port to connected PoE-enabled devices. Power over Ethernet simplifies deployment of surveillance devices and access point infrastructures by reducing cable clutter, and eliminating the need for dedicated power supplies to allow PoE devices to be installed in remote locations.
Lifetime Warranty and NBD Replacement
D-Link offers a Lifetime Warranty and Next Business Day (NBD) hardware replacement on the DMS-1100 Series 2.5 Gigabit Ethernet Smart Managed switches to further its commitment to product quality and long-term customer confidence.
Data transmission
Jumbo frames
9216
Jumbo frames support
Yes
MAC address table
16000 entries
Store-and-forward
Yes
Switching capacity
80 Gbit/s
Throughput
59.52 Mpps
Design
Certification
CE, FCC, C-Tick, VCCI, BSMI, CCC
Form factor
1U
LED indicators
Activity, Fan fail, Link, PoE, Power, Speed
Number of fans
1 fan(s)
Product colour
Black
Rack mounting
Yes
Safety
cUL, CB, CE, CCC, BSMI
Management features
MIB support
RFC768 UDP, RFC791 IP, RFC792 ICMP, RFC793 TCP, RFC826 ARP, RFC1213 MIB II, RFC768 UDP, RFC791 IP, RFC792 ICMP, RFC793 TCP, RFC826 ARP, RFC1213 MIB II
Quality of Service (QoS) support
Yes
Switch layer
L2
Switch type
Managed
System event log
Yes
Multicast features
MLD entries
192
Multicast support
Yes
Network
10G support
Yes
Auto MDI/MDI-X
Yes
Cable types supported
Cat5e
Copper ethernet cabling technology
100BASE-TX, 1000BASE-T
Ethernet Ring Protection Switching (ERPS)
Yes
Flow control support
Yes
Head-of-line (HOL) blocking
Yes
Link aggregation
Yes
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs
4094
Port mirroring
Yes
Spanning tree protocol
Yes
Virtual LAN features
Voice VLAN, Tagged VLAN, Port-based VLAN
VLAN support
Yes
Operational conditions
Operating relative humidity (H-H)
0 - 95 %
Operating temperature (T-T)
-5 - 50 �C
Storage relative humidity (H-H)
0 - 95 %
Storage temperature (T-T)
-40 - 70 �C
Optical fiber
Fiber ethernet cabling technology
1000BASE-X
Package dimensions
Depth (package,cm)
52.1 cm
Gross Weight (Package, kg)
3.43 kg
Height (package,cm)
9.2 cm
Width (package,cm)
36.5 cm
Performance
Harmonized System (HS) code
85176990
Maximum cable length
100 m
Mean time between failures (MTBF)
676329 Hour
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
2.5G Ethernet (100/1000/2500)
SFP+ module slots quantity
2
Power
AC input voltage
100 - 240 V
Power consumption (max)
293.4 Watt
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
8
Total Power over Ethernet (PoE) budget
240 Watt
Product dimensions
Net Weight (Product, kg)
3.33 kg
Product Depth
25 cm
Product Height
4.4 cm
Product Width
44 cm
Security
DHCP features
DHCP client
DoS attack prevention
Yes
IGMP entries
192
IGMP snooping
Yes
Queue scheduling algorithms
Strict Priority Queue (SPQ), Deficit weighted round robin (DWRR), Weighted Round Robin (WRR)
Security algorithms
SNMP, SSL/TLS
Vendor information
Brand Name
D-Link
Warranty
5 Year(s)
View AllClose
