Dell VJ454 Poweredge R660Xs Server 960 VJ454

The perfect blend of performance and density
Run the most popular IT applications easily with this air-cooled server that is the best choice for balanced and dense compute.

Design



Bezel



Yes


Chassis type



Rack (1U)


Product colour



Black


Rack rails



Yes


Graphics



On-board graphics card



No


Memory



Buffered memory type



Registered (buffered)


Internal memory



32 GB


Internal memory type



DDR5-SDRAM


Maximum internal memory



1 TB


Memory data transfer rate



4800 MT/s


Memory layout (slots x size)



1 x 32 GB


Memory ranking



2


Memory slots



16x DIMM


Network



Cabling technology



10/100/1000Base-T(X)


Ethernet interface type



Gigabit Ethernet


Ethernet LAN



Yes


LAN controller



Broadcom 5720


Operational conditions



Non-operating altitude



0 - 12000 m


Operating altitude



0 - 3048 m


Operating temperature (T-T)



10 - 35 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-40 - 65 �C


Other features



Bytes per sector



512


Data transfer rate



6 Gbit/s


Package dimensions



Gross Weight (Package, kg)



1.29 kg


Performance



Remote administration



iDRAC9, Enterprise 16G


Trusted Platform Module (TPM)



Yes


Trusted Platform Module (TPM) version



2.0


Ports & interfaces



Ethernet LAN (RJ-45) ports



4


USB 2.0 ports quantity



2


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



1


Power



Number of redundant power supplies installed



2


Number of redundant power supplies supported



2


Power cable connector 1



C13 coupler


Power cable connector 2



C14 coupler


Power cable current



12 A


Power cable length



2 m


Power supply



1100 Watt


Power supply input voltage



100 - 240 V


Redundant power supply (RPS) support



Yes


Processor



Maximum internal memory supported by processor



512 GB


Number of processors installed



1


Processor boost frequency



4 GHz


Processor cache



30 MB


Processor cores



16


Processor family



Intel� Xeon� Gold


Processor frequency



2 GHz


Processor manufacturer



Intel


Processor model



5416S


Thermal Design Power (TDP)



150 Watt


Product dimensions



Net Weight (Product, kg)



0.99 kg


Product Height



4.28 cm


Product Width



43.4 cm


Software



Compatible operating systems



Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware vSAN/ESXi


Operating system installed



No


Storage



Hot-Plug support



Yes


Internal drive bays



8


Number of SSDs installed



2


RAID support



Yes


SSD capacity



480 GB


SSD interface



SATA III


SSD size



2.5"


Supported RAID controllers



PERC H755


Supported storage drive interfaces



SAS, Serial ATA


Total storage capacity



960 GB


Vendor information



Brand Name


Dell


Warranty



1 Year(s)
