Fractal Design
Fractal Design FD-WCU-CELSIUS-S24-BKO Celsius S24 Bko Processor FD-WCU-CELSIUS-S24-BKO
(No reviews yet)
Write a Review
- UPC:
- 0000000000000
- MPN:
- FD-WCU-CELSIUS-S24-BKO
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The Celsius series builds upon proven technology with cutting edge advancements and premium sound dampening materials to deliver extreme cooling performance with minimum noise output.
Smart dual mode speed controls are both simple and robust with no need for additional software. Both fan and pump speeds can be managed by an intelligent auto mode or switched to PWM mode for precise user control.
For true enthusiasts, the satisfaction of a clean and efficient build can never be overstated, and the Celsius makes this easier than ever with an integrated fan hub and concealed cable routing.
Design
Base plate material
Copper
Product colour
Black
Radiator material
Aluminium
Logistics data
Harmonized System (HS) code
84733080
Other features
Number of fans supported
2
Tube material
Rubber
Package dimensions
Depth (package,cm)
14.4 cm
Gross Weight (Package, kg)
0.26 kg
Height (package,cm)
17.7 cm
Width (package,cm)
41 cm
Packaging content
Manual
Yes
Screws included
Yes
Performance
Airflow
148.8 m�/hr
Fan noise level (max)
32.2 dB
Fan speed (max)
2000 RPM
Fan speed (min)
500 RPM
Fan static pressure
2.3 mmH2O
Fan's mean time to failure (MTTF)
100000 Hour
Maximum airflow
87.6 cfm
Pulse-width modulation (PWM) support
Yes
Pump motor speed (max)
3150 RPM
Pump motor speed (min)
1950 RPM
Pump noise level
20 dB
Pump's mean time to failure (MTTF)
50000 Hour
Quantity per pack
1 pc(s)
Suitable location
Processor
Supported processor sockets
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+, Socket TR4
Type
All-in-one liquid cooler
Power
Fan current
0.2 A
Fan voltage
12 V
Pump current
1500 mA
Pump power consumption
6.6 Watt
Pump voltage
12 V
Product dimensions
Net Weight (Product, kg)
0.2 kg
Vendor information
Brand Name
Fractal Design
Warranty
1 Year(s)
Weight & dimensions
Radiator depth
12.2 cm
Radiator height
3.1 cm
Radiator width
28.4 cm
Tube length
40 cm
