Fractal Design
Fractal Design FD-WCU-CELSIUS-S36-BKO Celsius S36 Processor FD-WCU-CELSIUS-S36-BKO
(No reviews yet)
Write a Review
- UPC:
- 0000000000000
- MPN:
- FD-WCU-CELSIUS-S36-BKO
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Celsius S36
The Celsius series is all about delivering the best possible cooling with the least possible noise.
No additional software needed
Both fan and pump speeds can be managed by an intelligent auto mode or switched to PWM mode for precise user control. For true enthusiasts, the satisfaction of a clean and efficient build can never be overstated, and the Celsius makes this easier than ever with an integrated fan hub and concealed cable routing.
Key features
- Included Fractal Design Dynamic X2 PWM fans offer a wide speed adjustment range from 500 to 2000 RPM allowing for near silent operation under lighter loads and maximum airflow during heavy usage
- Radiator fittings use standard G 1/4" thread for maximum compatibility and expandability with standard do-it-yourself components
- Easily add and integrate a GPU block of your choice to eliminate noisy graphics card fans so the only sound you hear is the sound of your game
Dynamic X2 PWM fans
Included Fractal Design Dynamic X2 PWM fans
Premium sound dampening materials
An intelligent temperature-controlled auto mode adjusts fan and pump speeds in real-time for optimum balance of cooling performance and silence, while PWM mode enables precision manual tuning for any usage situation.
Standard G 1/4 thread fittings
Radiator fittings use standard G 1/4" thread for maximum compatibility and expandability with standard DIY components.
Design
Base plate material
Copper
Fan controller
Yes
Number of fans
3 fan(s)
Product colour
Black
Radiator material
Aluminium
Logistics data
Harmonized System (HS) code
84733080
Other features
Thermal grease
Yes
Tube material
Rubber
Package dimensions
Depth (package,cm)
14.4 cm
Gross Weight (Package, kg)
0.26 kg
Height (package,cm)
17.7 cm
Width (package,cm)
47.2 cm
Performance
Airflow
148.8 m�/hr
Fan noise level (max)
32.2 dB
Fan speed (max)
2000 RPM
Fan speed (min)
500 RPM
Fan static pressure
2.3 mmH2O
Maximum air pressure
1000 mmH2O
Maximum airflow
87.6 cfm
Mean time between failures (MTBF)
100000 Hour
Pulse-width modulation (PWM) support
Yes
Pump motor speed (max)
3150 RPM
Pump motor speed (min)
1950 RPM
Pump noise level
20 dB
Pump's mean time to failure (MTTF)
50000 Hour
Suitable location
Processor
Supported processor sockets
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+, Socket TR4
Type
All-in-one liquid cooler
Power
Fan current
0.2 A
Fan voltage
12 V
Pump current
0.15 mA
Pump voltage
12 V
Product dimensions
Net Weight (Product, kg)
0.2 kg
Vendor information
Brand Name
Fractal Design
Warranty
1 Year(s)
Weight & dimensions
Radiator depth
3 cm
Radiator height
12.3 cm
Radiator width
40.3 cm
Tube length
40 cm
