Hanwha QND-8011. Type: Ip Security Camera Placement Supported: Indoor & Outdoor QND-8011

Hanwha QND-8011. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Minimum illumination: 0.15 lx, Lens viewing angle, horizontal: 104.4??, Lens viewing angle, vertical: 76.7??. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"), Number of effective pixels (H x V): 2592 x 1944 pixels. Fixed focal length: 2.8 mm Max. 5Megapixel (2592 x 1944) resolution 2.8mm fixed lens 0.15Lux (Color), WDR (120dB) Max. 30fps@5MP (H.265 / H.264) H.265, H.264, MJPEG codec support, Multiple streaming Tampering, Motion detection, Defocus detection Micro SD / SDHC / SDXC memory slot (Max. 128GB) Hallway view, WiseStream II support LDC, PoE
Packaging content

Number of cameras1

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Storage

Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Card reader integratedYes

System requirements

Windows operating systems supportedYes
Mac operating systems supportedYes

Lens system

Maximum aperture number2
Fixed focal length2.8 mm
Fixed focusYes

Power

Power consumption (typical)4 W
Power source typePoE
Power consumption (max)5 W

Weight & dimensions

Weight165 g
Height56 mm
Diameter9.9 cm

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes
Number of effective pixels (H x V)2592 x 1944 pixels

Operational conditions

Operating relative humidity (H-H)0 - 90%
Storage temperature (T-T)-30 - 60 ??C
Operating temperature (T-T)-10 - 40 ??C
Storage relative humidity (H-H)0 - 90%

Security

Video motion detectionYes
Active tampering alarmYes
IP address filteringYes
Alert notification typeE-mail

Performance

TypeIP security camera
Connectivity technologyWired
Languages supportSimplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish
Placement supportedIndoor & outdoor
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes


Design

Form factorDome
Product colourWhite
Housing materialPlastic
Mounting typeCeiling
International Protection (IP) codeIP42
IK codeIK08

Camera

White balanceATW, AWC, Indoor, Manual, Outdoor
Minimum illumination0.15 lx
Tilt angle range0 - 69??
Pan range0 - 350??
Camera shutter typeElectronic
Adjustment shutter speedManual
Lens viewing angle, horizontal104.4??
Lens viewing angle, vertical76.7??
Lens viewing angle, diagonal136.1??

Network

Supported network protocolsIPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
Ethernet LANYes
Number of users6 user(s)
Networking standardsIEEE 802.1x
BluetoothNo
Wi-FiNo
Quality of Service (QoS) supportYes
Ethernet interface type10 Gigabit Ethernet, 100 Gigabit Ethernet
Streaming methodMulticast, Unicast

Video

Maximum resolution2592 x 1944 pixels
Video compression formatsH.264, H.265, M-JPEG
Noise reductionYes
Supported graphics resolutions640 x 360, 640 x 480 (VGA), 720 x 480, 768 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 960, 1920 x 1080 (HD 1080), 2592 x 1944
Total megapixels5 MP
Back Light Compensation (BLC)Yes
Video streamingYes
Flip & mirrorYes
Gain control typeManual
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
