Hewlett Packard Enterprise JG641A 830 8P PoE+ Unifd Wired-WLAN JG641A

The HP 830 Unified Wired-WLAN Switch Series integrates both wireless controller and GbE switch functions. The switch series provides 1000 Mb/s Ethernet ports, each supporting up to 30 W of PoE+ and manages IEEE 802.11a/b/g/n/ac APs to deliver unified access, consistent policy and RF optimization for your small to medium branch offices.

The HP 830 24-Port PoE+ Unified Wired-WLAN Switch provides two optional 10GbE slots on the rear panel to relieve transmission bottleneck at the core of a WLAN network. The HP 830 Unified Wired-WLAN Switch Series are part of the HPN Mobility enterprise solution.

Enhanced Performance and Unified Access for Branch Offices.
The HP 830 Unified Wired-WLAN Switch Series accommodates the growth of mobile devices by offering unified wired and wireless services in a single device, which can support up to 1000 wireless users and comes with 8 or 24 Gigabit Ethernet PoE+ ports.
Supporting Point 1.2: Supports both centralized and distributed forwarding options for unparalleled application performance and WLAN scalability.
Offers a self-optimizing wireless network with Wi-Fi Clear Connect RF optimization, automatic interference mitigation and dynamic client load balancing for enhanced connectivity in dense client environments.
Supports N+1, N+N redundancy, to provide continuity of services in branch offices.
Provides granular access control policies based on Committed Access Rate (CAS), QoS profiles, SSID or access point location for user, application and BYOD initiatives.

Robust Security and Threat Protection.
The HP 830 Unified Wired-WLAN Switch Series provides integrated wireless intrusion detection and prevention and supports Virtual Service Domains to deploy security policies by department or location.
Provides robust security and threat protection with support for embedded or external authentication servers and integrated Endpoint Admission Defense (EAD).
Provides role or SSID based access through embedded firewall to protect clients from outside attacks and restrict access to specific network resources.

Reduced Total Cost of Ownership (TCO) and Simplified Management.
The HP 830 Unified Wired-WLAN Switch Series reduces TCO with supports for industry leading Lifetime Warranty 2.0 and 3 year 24x7 phone support.
Simplifies configuration, management and troubleshooting and policy enforcement for wired and wireless network with HP single management tool.
Reduces the cost of ownership by integrating wired and wireless connectivity in a single device eliminating the need to purchase separate wired and wireless access devices.

Data transmission



MAC address table



8000 entries


Design



Form factor



1U


Product colour



Black


Rack mounting



Yes


Stackable



No


Management features



Quality of Service (QoS) support



Yes


Switch layer



L3


Switch type



Managed


Web-based management



Yes


Multicast features



Multicast support



Yes


Network



10G support



No


Auto MDI/MDI-X



Yes


Full duplex



Yes


IP routing



Yes


Link aggregation



Yes


Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3u


Spanning tree protocol



Yes


Operational conditions



Heat dissipation



130 BTU/h


Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 45 °C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-40 - 70 °C


Package dimensions



Gross Weight (Package, kg)



5.65 kg


Performance



Flash memory



1024 MB


Internal memory



512 MB


Memory type



DDR2-SDRAM


Processor frequency



750 MHz


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



8


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Console port



RJ-45


Power connector



DC-in jack


SFP module slots quantity



2


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Power consumption (typical)



38 Watt


Power supply included



No


Power over Ethernet (PoE)



Power over Ethernet (PoE)



Yes


Total Power over Ethernet (PoE) budget



180 Watt


Product dimensions



Net Weight (Product, kg)



5.550000000000001 kg


Product Depth



27 cm


Product Height



4.36 cm


Product Width



44 cm


Security



DHCP features



DHCP server, DHCP client


IGMP snooping



Yes


Vendor information



Brand Name


Hewlett Packard Enterprise


Warranty



1 Year(s)
