IBM 46C8988-RFB IBM N2115 SAS/SATA HBA for 46C8988-RFB

The N2115 SAS/SATA HBA for IBM System x is an ideal solution for System x servers requiring high-speed internal storage connectivity. This 8-port host bus adapter supports direct attach to SAS and SATA internal hard disk drives and solid-state drives (SSDs).

The N2125 SAS/SATA HBA for IBM System x is a low-cost, high-performance 8-port host bus adapter perfect for high-performance connectivity between System x servers and external storage JBOD, Tape, and RAIDed units.

With low-profile form factor designs, the N2115 SAS/SATA HBA for IBM System x and the N2125 SAS/SATA HBA for IBM System x offer two (x4) internal mini-SAS connectors and two (x4) external mini-SAS connectors, respectively. They are based on LSI 2308 6 Gbps SAS IO controller; both provide eight lanes of 6 Gbps SAS and eight lanes of PCIe 3.0 to eliminate data bottlenecks and provide high data transfer rates for medium-to-large capacity server storage applications.

Design



Certification



UL cUL IEC60950 EMC FCC TUV CE VCCI BSMI C-tick KC


Internal



Yes


Purpose



Server


Features



Chipset



LSI SAS2308


Data transfer rate (max)



6 Gbit/s


Operational conditions



Operating relative humidity (H-H)



8 - 93 %


Operating temperature (T-T)



5 - 40 �C


Package dimensions



Depth (package,cm)



5.08 cm


Gross Weight (Package, kg)



2.9 kg


Height (package,cm)



23.83 cm


Width (package,cm)



14.3 cm


Packaging data



User guide



Yes


Ports & interfaces



Connector(s)



8 x SAS+SATA, 2 x mini-SAS


Host interface



PCIe


Output interface



SAS, SATA


Product dimensions



Net Weight (Product, kg)



2.8 kg


Product Depth



1.75 cm


Product Height



6.45 cm


Product Width



15.24 cm


System requirements



Linux operating systems supported



Yes


Windows operating systems supported



Y, Yes


Vendor information



Brand Name


IBM


Warranty



1 Year(s)
