Intel Core Ultra 5 245KF Intel Core Ultra 5 FCLGA1851 Intel 245KF 64-bit Intel C BX80768245KF

Intel Core Ultra 5 245KF. Processor family: Intel Core Ultra 5, Processor socket: FCLGA1851, Processor manufacturer: Intel. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 22 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. L2 cache: 26624 KB, Maximum internal memory: 192 GB

Graphics


On-board graphics card

No


On-board graphics card model

Not available


Discrete graphics card

No


Discrete graphics card model

Not available



Processor special features


Intel Speed Shift Technology

Yes


Mode-based Execute Control (MBE)

Yes


Enhanced Intel SpeedStep Technology

Yes


Intel Boot Guard

Yes


Intel Trusted Execution Technology

Yes


Intel Control-flow Enforcement Technology (CET)

Yes


Intel Standard Manageability (ISM)

Yes


Intel Turbo Boost Technology

2.0


Intel Virtualization Technology for Directed I/O (VT-d)

Yes


Intel Deep Learning Boost (Intel DL Boost) on CPU

Yes


Intel Virtualization Technology (VT-x)

Yes


Intel AES New Instructions (Intel AES-NI)

Yes


Intel Thunderbolt 4

Yes


Intel VT-x with Extended Page Tables (EPT)

Yes


Intel OS Guard

Yes


Intel Thread Director

Yes


Intel Secure Key

Yes


Intel Volume Management Device (VMD)

Yes


Intel 64

Yes



Processor


Processor base power
5 W


Processor operating modes

64-bit


Performance cores

6


Performance-core base frequency

4.2 GHz


Maximum turbo power
9 W


Processor family

Intel Core Ultra 5


Stepping

B0


Processor socket

FCLGA1851


Processor boost frequency

5.2 GHz


Processor ARK ID

241066


Efficient-core base frequency

3.6 GHz


AI software frameworks supported by CPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN


Processor generation

Intel Core Ultra (Series 2)


Processor codename

Arrow Lake


Processor cache

24 MB


Box

Yes


Efficient-core boost frequency

4.6 GHz


Efficient cores

8


Processor cache type

Smart Cache


Maximum number of DMI lanes

8


Performance-core boost frequency

5.2 GHz


Cooler included

No


Processor model

245KF


Processor manufacturer

Intel


Processor cores




Neural processor unit (NPU)


Windows Studio effects support

Yes


Neural processor unit (NPU)

Intel AI Boost


AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN


Sparsity support

Yes


Total processor performance up to

22 TOPs


NPU performance up to
TOPs



Logistics data


Harmonized System (HS) code

8542310050



Memory


Memory types supported by processor

DDR5-SDRAM


Maximum internal memory supported by processor
2 GB


Memory clock speeds supported by processor

6400 MHz


Memory channels

Dual-channel



Technical details


Status

Launched


Launch date

Q4'24


Memory speed (max)

6400 MHz



Other features


L2 cache

26624 KB


Maximum internal memory
2 GB



Features


Use conditions

PC/Client/Tablet


Direct Media Interface (DMI) Revision

4.0


Scalability

1S


Commodity Classification Automated Tracking System (CCATS)

740.17B1


Embedded options available

No


Execute Disable Bit

Yes


Export Control Classification Number (ECCN)

5A992C


Thermal Monitoring Technologies

Yes


PCI Express slots version

4.0, 5.0


Idle States

Yes


Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2


Maximum number of PCI Express lanes

24


Market segment

Desktop


Thermal solution specification

PCG 2020A



Operational conditions


Maximum operating temperature
5 C
