Intel FTXL710-BM1 � Ethernet Controller FTXL710-BM1

Intel� Data Direct I/O Technology
Intel� Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel� Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.

PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.

Intel� Ethernet Power Management
Intel� Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.

Fiber Channel over Ethernet
Fibre Channel over Ethernet (FCoE) is an encapsulation of Fibre Channel frames over Ethernet networks. This allows Fibre Channel to use 10 Gigabit Ethernet networks (or higher speeds) while preserving the Fibre Channel protocol.

IEEE 1588
IEEE 1588, also knows as the Precision Time Protocol (PTP) is a protocol used to synchronize clocks throughout a computer network. On a local area network it achieves clock accuracy in the sub-microsecond range, making it suitable for measurement and control systems.

Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.

Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance

Features



Commodity Classification Automated Tracking System (CCATS)



NA


Export Control Classification Number (ECCN)



5A991


Fiber Channel over Ethernet



No


Intelligent Offloads



Yes


Jumbo frames support



Yes


Launch date



Q4'15


Lithography



28 nm


On-board graphics card



No


On-chip QoS and Traffic Management



Yes


Package size



25 x 25 mm


PCI-SIG* SR-IOV Capable



Yes


Product codename



Fortville


Product series



700 Series Controllers (up to 40GbE)


Status



Launched


Storage Over Ethernet



iSCSI, NFS


Thermal Design Power (TDP)



7 Watt


Logistics data



Harmonized System (HS) code



8542310001


Network



Ethernet LAN data rates



1000, 10000, 40000


Network controller sideband interface (NC-SI)



Yes


Operational conditions



Maximum operating temperature



55 �C


Operating temperature (T-T)



0 - 55 �C


Package dimensions



Gross Weight (Package, kg)



0.39 kg


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Host interface



PCI Express


PCI Express slots version



3.0


Processor special features



Intel Data Direct I/O Technology



Yes


Intel Ethernet Power Management



Yes


Intel Flexible Port Partitioning



Yes


Intel Virtual Machine Device Queues (VMDq)



Yes


Product dimensions



Net Weight (Product, kg)



0.3 kg


Vendor information



Brand Name


Intel


Warranty



1 Year(s)
