J5create 130W Gan Usb-C 4-Port Charger JUP43130F-FN

Product Group:

Chargers



Manufacturer:

J5CREATE



SKU:
6868


Product Specifications



Product Name:

J5Create 130W GaN USB-C 4-Port Charger UK



Web Address:

en.j5create.com



Model Number:

JUP43130F-FN



EAN:

4712795086706



Package Type:

Retail



Warranty:

2 Years



Colour:

White and Gray



Enclosure Type:

Plastic



Connector:

UK Power Plug



Power Output:

3 x USB-C Female
1 x USB Type-A Female



Max Wattage Output:

Output 3: 5V/3A, 9V/2.22A, 12V/1.67A (Max 20W)
USB-C Output Half: 5V/3A, 9V/3A, 12V/3A, 15V/3A and 20V/5A (Max 100W)
USB Type A Output: 3.6V-6V/3A, 6V-9V/2A, 9V-12V/1.5A (Max 18W)



Power:
0V - 240V; 50/60 Hz; 2A Max



Temperature:

Operating: 0 to 30-C



Product Width:

69mm



Product Length:

32mm



Product Height:

87mm



Product Weight:

295g



Package Width:

9.5cm



Package Length:
.5cm



Package Height:

4cm



Gross Weight:

0.37Kg



Special Features:

Designed to provide an enormous 130W of power in a smaller form factor.
The combined power output of the 3-port USB-C power delivery ports and the USB Type-A port.
Charging USB-C and USB Type-A port simultaneously automatically balances the charging output up to 130W:The first and the second USB-C port provide up to 100W of power when used independently.
The first and the second USB-C port provide up to 65W of power when both ports are used. (Dynamic Power Control of full load in 30 mins: PD90W(PD45W+PD45W)
The third USB-C port provides up to 20W of power when used independently.
The USB Type-A port provides up to 18W of power when used independently.
The third USB-C and USB Type-A port provide up to 20W (5V/2A+5V/2A) of power when used both ports.



Package Contents:

1 x 130W GaN USB-C 4-Port Charger
1 x Quick Installation Guide (QIG)
