J5create Usb4 8K Multi-Port Hub JCD403-N

Product Group:

Adapters & Docks



Manufacturer:

J5CREATE



SKU:
6891


Product Specifications



Product Name:

J5Create USB4 8K Multi-Port Hub



Web Address:

en.j5create.com



Model Number:

JCD403-N



EAN:

4712795086614



Package Type:

Retail



Warranty:

2 Years



Enclosure Type:

Aluminium



Colour:

Space Grey



Hardware:

Host Connector: 1 x USB4 Male
Video Output: 1 x HDMI Female
Power Source: Bus-powered or self-powered
Network Interface: Yes
Audio Supported: Yes
Ports:1 x USB-C 3.2 Gen2 10Gbps data transmission
1 x USB-C power delivery 3.0 100W
2 x USB Type-A 3.2 Gen2 10Gbps data transmission
1 x 8K HDMI
1 x RJ45 2.5 Gigabit Ethernet



Performance:

Maximum Display Resolution: 7680 x 4320
Maximum Display Refresh Rate: 60 Hz at 3840 x 2160 / 144 Hz at 3840 x 2160 (Only for DSC host) / 30 Hz at 7680 x 4320 / 60 Hz at 7680 x 4320 (Only for DSC host)
Maximum Data Transfer Rate: 10Gbps
Displays Supported: HDMI
Compatible Networks: 10M/100M/1000M/2.5 Gigabit
Audio Channel: 1 x 2.1 via HDMI



Power:

Power Delivery: Up to 100W via USB-C
Power Consumption: = 900 mA
Input Current: Up to 5A
Input Voltage: Up to 20V
Output Current: Up to 4.75A
Output Voltage: Up to 20V



Cable Length:
0mm



Temperature:

Operating: -1 to 41-C
Storage: -17 to 68-C)



Humidity:

< 85% non-condensing



Product Width:

51mm



Product Length:
mm



Product Height:
5mm



Product Weight:
9g



Package Width:
.5cm



Package Length:
.3cm



Package Height:

2.25cm



Gross Weight:

0.17Kg



Special Features:

Supports resolutions up to 8K.
Compatible with Thunderbolt 4, Thunderbolt 3 or other USB-C host laptops.
Thunderbolt 4, USB4 is required to achieve 8K resolutions.
Also supports other USB 3.2 host laptops and lower resolution monitors/displays.
One 2.5 Gigabit Ethernet port for a high-speed multi-gig network connection.
Two SuperSpeed+ USB Type-A 10Gbps port to accommodate your legacy peripheral.
One USB-C downstream port supports up to 10Gbps data transmission.
Power Delivery 3.0 offers up to 100W of pass-through charging.
Multiple data and display protocols efficiently share bandwidth to offer optimal performance.
Wide compatibility with various operating systems and devices.
Plug-and-play, no driver installation required.



Package Contents:

1 x JCD403 USB4 8K Multi-Port Hub
1 x Quick Installation Guide (QIG)
