Product Overview
The FSW-2450 switch provides an ideal solution for small businesses that demand a reliable network switch that provides a high bandwidth interface between file servers and workgroups, departments and offices.

Advanced Networking Features
The LevelOne FSW-2450 is a wire-speed, nonblocking 24 port Fast Ethernet Unmanaged Switch with an internal power supply. It provides a network with an 8K MAC address table, 4.8Gbps backplane throughput, asymmetrical flow-control support for full-duplex network connectivity, auto-negotiation and Auto-MDIX.

The 24-port Fast Ethernet Switch utilizes packet store-and forwarding switching for error-free data transmissions and IEEE802.3x backpressure flow control to control data flow between the sending and receiving nodes as well as to prevent any data packet loss.

Compact Design
The FSW-2450 is a compact designed network switch. Users can place the switch on any desktop area or mount it in a 19-inch server rack or cabinet by using the included rack-mounting accessory kit.

Quick Configuration and Easy Maintenance
The LevelOne FSW-2450 does not require any software configuration. It is Plug-and-Play enabled for quick set-up and immediate use within the Local Area Network. The 24 port Fast Ethernet Switch is equipped with a full range of LEDs for instant error detection, networking monitoring and network troubleshooting.

Data transmission



MAC address table



8192 entries


Packet buffer memory



0.16 MB


Store-and-forward



Yes


Switching capacity



4.8 Gbit/s


Design



Certification



FCC Class A, CE, RoHS


LED indicators



Activity, Link, Power


Product colour



Black


Rack mounting



Yes


Logistics data



Harmonized System (HS) code



85176990


Master (outer) case gross weight



11.64 kg


Master (outer) case height



24 cm


Master (outer) case length



50 cm


Master (outer) case width



40.5 cm


Management features



Quality of Service (QoS) support



Yes


Switch type



Unmanaged


Network



10G support



No


Auto MDI/MDI-X



Yes


Auto-negotiation



Yes


Cable types supported



Cat5


Copper ethernet cabling technology



10BASE-T, 100BASE-TX


Flow control support



Yes


Full duplex



Yes


MAC address auto-learning supported



Yes


Networking standards



IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3z


Rate limiting



Yes


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 °C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-40 - 70 °C


Package dimensions



Depth (package,cm)



48.6 cm


Gross Weight (Package, kg)



6.07 kg


Height (package,cm)



7.7 cm


Width (package,cm)



22.4 cm


Packaging data



Cables included



AC


Quick start guide



Yes


Rack mount kit



Yes


Performance



Harmonized System (HS) code



85176990


Maximum cable length



100 m


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



24


Basic switching RJ-45 Ethernet ports type



Fast Ethernet (10/100)


Power connector



DC-in jack


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Power consumption (typical)



10 Watt


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



4.83 kg


Product Depth



44 cm


Product Height



4.4 cm


Product Width



14 cm


Protocols



Switching protocols



CSMA, CD


Vendor information



Brand Name


LevelOne


Warranty



2 Year(s)
