Levelone
LevelOne FVS-3120 10/100BASE-TX-100BASE-LX SMF FVS-3120
(No reviews yet)
Write a Review
- UPC:
- 4015867160183
- MPN:
- FVS-3120
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The LevelOne Web Smart Media Converter FVS-3120 is designed to make conversion between
10/100BASE-TX and 100BASE-LX SMF SC Ethernet.
With web-based management, the network administrator can logon to the converter remotely to monitor, configure and control the status of each unit. The overall network reliability is enhanced, and the network efficiency is also improved to accommodate and deliver high bandwidth applications.
- HTTP Management with remote firmware upgrade supported
- ICMP and ARP protocols supported
- DHCP Client for easy IP address setup
- LLR (Link Loss Return) supported
- IEEE 802.1Q VLAN and Double VLAN (Q-in-Q) supported
- Support 802.3x Flow Control to prevent lost data by controlling the device flow loading
Design
Certification
FCC Part 15 Class A, CE
Internal
No
Product colour
Grey
Network
Converter input interface
10Base-T, 100Base-TX
Converter output interface
100Base-LX
Ethernet interface type
Fast Ethernet
Ethernet LAN data rates
10, 100
Flow control support
Yes
Jumbo frames support
Yes
Maximum data transfer rate
100 Mbit/s
Networking standards
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x
Operational conditions
Operating relative humidity (H-H)
5 - 90 %
Operating temperature (T-T)
0 - 50 °C
Package dimensions
Depth (package,cm)
22 cm
Gross Weight (Package, kg)
0.46 kg
Height (package,cm)
6 cm
Width (package,cm)
16 cm
Packaging content
Manual
Yes
Performance
Fiber cable diameters supported (core/cladding)
3/125, 8.7/125, 9/125, 10/125
Fiber mode structure
Single-mode
Maximum transfer distance
20000 m
Ports & interfaces
Connectivity technology
Wired
DC-in jack
Yes
Ethernet LAN (RJ-45) ports
1
Fiber optic connector
SC
Fiber ports quantity
1
Power
External power adapter
Yes
Input current
1 A
Input voltage
5 V
Power consumption (typical)
1.5 Watt
Product dimensions
Product Depth
9.4 cm
Product Height
2.62 cm
Product Width
7.03 cm
Vendor information
Brand Name
LevelOne
Warranty
1 Year(s)
