LevelOne NVR-0504 4CH NVR 4-PORT POE IEEE 802.3A NVR-0504

The LevelOne NVR-0504 NVR enables live view, recording and playback for up to 4 IP network cameras at the same time, featuring up to 8-megapixel resolution and H.265/H.264+/H.264 video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. Mobile device operations are also supported (iOS/Android), with remote viewing via the LevelOne NVR app.

The NVR also features built-in HDMI, VGA and USB ports for peripheral devices such as a monitor, mouse or keyboard, allowing users to operate directly from the NVR without the cost of adding a PC to the deployment. One HDD bay completes the package, with a disk capacity of up to 6TB making the LevelOne NVR-0504 a powerful, smart and cost-effective solution for managing your security network.

An integrated 4-port 802.3at PoE switch enables the NVR to run both power and data on the one cable to power up connected PoE cameras.

Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications.

Features



Certification



CE, FCC, ISO9001, ISO14001


LED indicators



HDD, Power


On/off switch



Yes


Product colour



Black


RoHS compliance



Yes


Logistics data



Master (outer) case gross weight



12.8 kg


Master (outer) case height



31.3 cm


Master (outer) case length



50.3 cm


Master (outer) case width



72.3 cm


Products per master (outer) case



8 pc(s)


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



-10 - 55 �C


Package dimensions



Depth (package,cm)



29 cm


Gross Weight (Package, kg)



1.15 kg


Height (package,cm)



8.5 cm


Width (package,cm)



48.5 cm


Packaging content



AC adapter included



Yes


Cables included



AC


CD manual



Yes


Performance



Maximum resolution



3840 x 2160 Pixels


Number of users



32 user(s)


Operating system installed



Embedded LINUX


Throughput data rate



80 Mbit/s


Video formats supported



H.264, H.265, MPEG4


Video input channels



4 channels


Ports & interfaces



Audio RCA inputs



1


Audio RCA outputs



1


Ethernet LAN (RJ-45) ports



4


HDMI output



Yes


HDMI ports quantity



1


Networking standards



IEEE 802.3at


Power over Ethernet (PoE)



Yes


Power over Ethernet (PoE) ports quantity



4


Supported network protocols



TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP


USB 2.0 ports quantity



2


VGA (D-Sub) output ports



1


Power



Power consumption (typical)



65 Watt


Product dimensions



Net Weight (Product, kg)



1 kg


Product Depth



4.8 cm


Product Height



31.5 cm


Product Width



24 cm


Storage



HDD size



3.5 "


Maximum storage capacity



6 TB


Number of HDDs supported



1


System requirements



Browser supported



Internet Explorer 9+


Mobile operating systems supported



Android, iOS


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


LevelOne


Warranty



1 Year(s)
