LevelOne OAN-4121 12Dbi 5Ghz Omnidirectional OAN-4121

The LevelOne OAN-4121 is an omni-directional antenna operating on the 5 GHz frequency that can be mounted either indoors or outdoors. The antenna�s gain value is 12dBi, and if mounted outdoors the weatherproof housing can withstand temperatures from minus 30�C up to 60�C, as well as rain, snow, dust and other harsh conditions.

- For IEEE 802.11a/n Wireless applications in 5 GHz frequency range
- Provides 12dBi omnidirectional operation
- Low wind loading
- 40�C to 70�C operating temperature range

Features



Antenna connector type



N-type


Antenna type



Omni-directional antenna


Connector gender



Female


Maximum cable loss with connectors



-10 dB


Mounting



Pole


Polarization



Vertical polarization


Product colour



White


Protection features



Dust resistant, Snow resistant, Water resistant


Purpose



Indoor & outdoor


Survival wind speed



180 kmh


Voltage Standing Wave Ratio (VSWR)



2.0


Logistics data



Harmonized System (HS) code



85177100


Master (outer) case gross weight



6 kg


Master (outer) case height



67 cm


Master (outer) case length



20.5 cm


Master (outer) case width



38.5 cm


Products per master (outer) case



10 pc(s)


Operational conditions



Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



-30 - 60 �C


Package dimensions



Depth (package,cm)



65 cm


Gross Weight (Package, kg)



0.39 kg


Height (package,cm)



7.2 cm


Width (package,cm)



8.3 cm


Packaging content



Mounting kit



Yes


Package type



Box


Quick installation guide



Yes


Performance



Antenna gain level (max)



12 dBi


Frequency band



5.45 ~ 5.835 GHz


Horizontal beam width



360 �


Impedance



50 ?


Networking standards



IEEE 802.11a, IEEE 802.11n


Vertical beam width



17.5 �


Product dimensions



Net Weight (Product, kg)



0.3 kg


Product Depth



55.85 cm


Product Height



5.3 cm


Product Width



7 cm


Vendor information



Brand Name


LevelOne


Warranty



1 Year(s)


Weight & dimensions



Diameter



30 cm
