Lindy 70M Cat.6 Dvi-D Single Link Extender. Maximum Resolution: 1920 X 1200 Pixe 38300

Lindy 70m Cat.6 DVI-D Single Link Extender. Maximum resolution: 1920 x 1200 pixels, Cable length: 70 m, Product colour: Black. Quantity per pack: 2 pc(s) With this Extender you can use up to 70m of high quality inexpensive Cat.5e/6 cable to connect a DVI source to a DVI display device. The slim RJ45 connectors and Cat.6 cable (not included) allow greater flexibility not possible with larger DVI connectors and cables. Normal operation will not require external power; however the Transmitter unit allows external power to be attached in cases where the graphics card does not provide sufficient power, either using a USB Micro-B Cable or an external power supply connected to the supplied USB to DC cable. The Extender supports the following resolutions/distance combinations: 800x600 = 70m 1024x768 = 65m 1280x1024 up to 1920x1200 = 50m Additional Requirements: RJ-45 patch cable: 1 xCAT5e/6 UTP Cable
Video

Maximum Video Resolution1920 x 1200

Media & Performance

Twisted Pair Cable StandardCategory 6
Media Type SupportedTwisted Pair

Miscellaneous

Package ContentsTransmitter Unit
Receiver Unit
USB Micro-B to DC Adapter Cable
Lindy Manual

Environmentally FriendlyYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

Physical Characteristics

Transmitter Height22 mm
Transmitter Width55 mm
Transmitter Depth40 mm
Receiver Height22 mm
Receiver Width55 mm
Receiver Depth40 mm
Transmitter Weight (Approximate)30 g
Receiver Weight (Approximate)30 g
Product ColorBlack
Color FamilyBlack


Technical Information

Connectivity TechnologyWired
Maximum Operating Distance70 m
Number of Output Devices Supported1
Number of Input Devices Supported1

General Information

Product TypeVideo Extender Transmitter/Receiver
Manufacturer Part Number38300
lindy
ManufacturerLindy Electronics
Product Name70m Cat.6 DVI-D Single Link Extender
Brand NameLINDY

Interfaces/Ports

Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Number of DVI Outputs1
DVI InYes
DVI OutYes
Number of DVI Inputs1
