LogiLink CV0038 DisplayPort-Mini CV0038

The Mini DisplayPort to VGA Adapter lets you connect a high definition
monitor, projector, or LCD that uses a VGA connector or cable to
a MacBook or MacBook Pro with a Mini DisplayPort.
Specifications
- Mini DisplayPort 1.1a compliant receiver offering 5.4 Gbps band
width over 2 lanes
- Integrated triple 10-bit, 162 MHz video DAC for analog VGA signal
output
- Supports up to 1080p, 1920 x 1200 reduced blanking video
resolution
- EDID pass-through from PC source to display
- Spread Spectrum (de-spreading) for EMI reduction
- Automatic sink detection
- Low power standby mode operation initiated based on sink
detection status
- Powered from Mini DisplayPort source
- 3.3V IO, 1.2V Core
- Low power operation � Active 400mW, standby mode 15mW.

Features



Cable length



0.09 m


Connector 1



VGA (D-Sub)


Connector 1 gender



Male


Connector 2



Mini DisplayPort


Connector 2 gender



Female


Product colour



Grey


Logistics data



Harmonized System (HS) code



84733080


Package dimensions



Gross Weight (Package, kg)



0.05 kg


Product dimensions



Net Weight (Product, kg)



0.04 kg


Vendor information



Brand Name


LogiLink


Warranty



4 Year(s)
