Mean Well HLG-600H-24B Power Supply Unit 600 W HLG-600H-24B

- Universal AC input / Full range (up to 305VAC)
- Built-in active PFC function
- No load power consumption <0.5W at remote OFF
- High efficiency up to 96%
- 40 ~ +70 �C wide operating range
- Protections: Short circuit / Over current / Over voltage / Over temperature
- Fanless design, cooling by free air convection
- IP67 / IP65 design for indoor or outdoor installations
- Withstand 5G vibration test
- Three in one dimming function (0~10Vdc or PWM signal or resistance)
- LED indicator for power on (A-Type)
- Suitable for dry / damp / wet location

Design



Product colour



Metallic


Operational conditions



Operating relative humidity (H-H)



20 - 95 %


Operating temperature (T-T)



-40 - 70 �C


Storage relative humidity (H-H)



10 - 95 %


Storage temperature (T-T)



-40 - 85 �C


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



Mean time between failures (MTBF)



76900 Hour


Safety



UL8750, CSA C22.2 No. 250.13-12, EN61347-1, EN61347-2-13 independent, IP67


Power



AC input frequency



47 - 63 Hz


AC input voltage



90 - 305 V


Efficiency



95 %


Hold time



15 Millisecond


Power Factor Correction (PFC) type



Active


Power protection features



Over current, Over voltage, Overheating, Short circuit


Total power



600 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



28 cm


Product Height



4.85 cm


Product Width



14.4 cm


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Mean Well


Warranty



1 Year(s)
