Mean Well PWM-120-24 Power Adapter/Inverter PWM-120-24

- PWM Output
- Even dimming of LED strip
- Dims down to Zero % of Output
- High Efficiency: Up to 90.5%
- 1.8M Flex & Plug
- Dimmable w/: Resistance, 0-10V, or PWM Signal

Design



Product colour



Black


Features



Efficiency



90 %


Input current



1.3 A


Input frequency



47/63 Hz


Input voltage



90-305 V


Output current



5 A


Output power



120 Watt


Output voltage



24 V


Power current type



AC-to-DC


Power protection features



Over voltage, Overheating, Overload, Short circuit


Power supply type



Universal


Purpose



Strip light


Operational conditions



Operating relative humidity (H-H)



20 - 95 %


Operating temperature (T-T)



-40 - 90 �C


Storage relative humidity (H-H)



10 - 95 %


Storage temperature (T-T)



-40 - 80 �C


Package dimensions



Gross Weight (Package, kg)



0.39 kg


Performance



Mean time between failures (MTBF)



860400 Hour


Product dimensions



Net Weight (Product, kg)



0.3 kg


Product Depth



19.1 cm


Product Height



3.75 cm


Product Width



6.3 cm


Vendor information



Brand Name


Mean Well


Warranty



1 Year(s)
