Moxa
Moxa 39511 REPEATER. RS-422/485 39511
- UPC:
- 5703431395114
- MPN:
- 39511
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
TCC-120 is an isolated RS-422/485 repeater designed for users who need an industrial grade interface conversion product to extend RS-422/485 transmission distance. Its superior industrial application design, which includes DIN-Rail mounting, terminal block wiring, external terminal block power, and optical isolation (TCC-120I) for system protection, makes TCC-120 series suitable for use in critical industrial environments.
Design
Certification
CE, FCC B
Network
Maximum data transfer rate
0.2304 Mbit/s
Operational conditions
Operating relative humidity (H-H)
5 - 95 %
Operating temperature (T-T)
20 - 60 °C
Storage temperature (T-T)
-20 - 85 °C
Other features
Dimensions (WxDxH)
90 x 100 x 22 mm
Interface
RS-422/485
Power requirements
12 - 48 VDC, 234 mA (12V)
Package dimensions
Depth (package,cm)
22 cm
Gross Weight (Package, kg)
0.35 kg
Height (package,cm)
8 cm
Width (package,cm)
16 cm
Ports & interfaces
Connectivity technology
Wired
Power
Power consumption (typical)
2.8 Watt
Product dimensions
Net Weight (Product, kg)
0.24999999999999997 kg
Vendor information
Brand Name
Moxa
Warranty
2 Year(s)
