MSI Cubi NUC 1M Intel Core 7 150U Desktop PC NUC SFF Mini Computer HTPC 16GB RAM 4.71138E+12

Cubi NUC 1M: The Sustainable & Energy Efficient Mini-PC

The MSI Cubi NUC 1M is a small yet powerful mini-desktop with an incredibly compact 0.826L design suitable for commercial office work or use as home-theatre/entertainment PC (supports UHD/4K 60Hz display output & quadruple-monitor setups).

The Cubi NUC 1M i7 150U FS 16GB 1TB W11P configuration is a complete system equipped with an Intel Intel® Core 7 processor 150U, 16GB of DDR5-5200MHz memory, 1TB of M.2 SSD storage, Intel Wi-Fi AX211 & Bluetooth 5.3 connectivity, as well as Windows 11 Pro software pre-installed.

The easy-to-upgrade SFF case can house both M.2 (1 x 2280, 1x 2242) & 2.5-inch storage, as well as up to 64 GB of system memory (2 x DDR5 SO-DIMM slots), and is VESA-mountable for a cleaner desktop.

Made with PCR (Post-consumer Recycled) plastic materials and recycled molded pulp tray packing design.

Front I/O connectivity includes a Mic-in/Headphone-out combo jack, 2x USB 10Gbps Type A and 1x Micro-SD card Reader. The rear I/O features dual 2.5Gbps ethernet LAN ports, 2x Thunderbolt 4, 2 x HDMI 2.1 and 2x USB 10Gbps Type A

Specs




Processor


Processor manufacturer

The manufacturer that produced the processor.

Intel


Processor family

A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.

Intel Core 7


Processor generation

Intel Core (Series 1)


Processor model

The model number for the processor in a computer.
0U


Processor cores

The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).



Processor threads



Performance cores

2


Efficient cores

8


Performance-core Max Turbo Frequency

5.4 GHz


Efficient-core Max Turbo Frequency

4 GHz


Performance-core base frequency

1.8 GHz


Efficient-core base frequency

1.2 GHz


Processor cache
MB


Number of processors installed

Number of processors in the product.

1


Processor base power
W


Maximum turbo power

55 W


Memory


Internal memory

A computer's memory which is directly accessible to the CPU.
GB


Maximum internal memory

The maximum internal memory which is available in the product.

64 GB


Internal memory type

The type of internal memory such as RAM, GDDR5.

DDR5-SDRAM


Memory layout (slots x size)

The slots and size of the memory for the CPU.

2 x 8 GB


Memory slots

Number and type of memory expansion slots, including connector and memory module descriptions.

2x SO-DIMM


Memory clock speed

The frequency at which the memory (e.g. RAM) runs.

5200 MHz


Storage


Total storage capacity

The total amount of data that can be stored on the device.

1 TB


Storage media

Used for the storage of data e.g. HDD (hard disk drive), SSD (solid-state drive).

SSD


Optical drive type

An optical drive uses laser to read optical discs such as CDs, DVDs and Blu-Ray. Some types of optical drive are: CD ROM drive, CR-RW (CD writer) drive, DVD-ROM.




Number of storage drives installed

Amount of storage drives built into the device.

1


Number of storage drives supported

How many storage drives can be fit into the product at once.

3


HDD size

The amount of data that the hard drive can store.

2.5"


Total SSDs capacity

1 TB


Number of SSDs installed

1


SSD capacity

The Solid State Drive's data storage capacity.

1 TB


SSD interface

The type of interface(s) with which the Solid State Drive is connected to other hardware.

M.2


NVMe

NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices.




SSD form factor

The size of the solid-state drive, given in inches

M.2


M.2 SSD size

2280 (22 x 80 mm)


Card reader integrated

A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.




Compatible memory cards

Types of memory cards which can be used with this product.

MicroSD (TransFlash)


Graphics


Discrete graphics card




On-board graphics card

Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.




Discrete graphics card model

A graphics adapter (often known as a video card) generates images for a display. A discrete graphics adapter plugs into the motherboard, and usually produces much better graphics than an integrated graphics adapter. There are various models of discrete graphics adapters.

Not available


On-board GPU manufacturer

Intel


On-board graphics card family

Intel Graphics


On-board graphics card model

"Graphic adapter" is the hardware that produces images on a display. "On-board" means that the graphics adapter is intergrated inside the motherboard.

Intel Graphics


Network


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




LAN controller

Intel I226-V


Wi-Fi

Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.




Top Wi-Fi standard

Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 6E (802.11ax)


Wi-Fi standards

The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

Wi-Fi 6E (802.11ax)


WLAN controller manufacturer

Intel


WLAN controller model

Intel Wi-Fi 6E AX211


Bluetooth

Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.




Bluetooth version

The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0).

5.3


Wake-on-LAN ready




Ports & interfaces


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4


PowerShare




USB Type-C DisplayPort Alternate Mode




Intel® Thunderbolt 4




Thunderbolt 4 ports quantity

2


DVI port

Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.




HDMI ports quantity

The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.

2



Ports & interfaces


HDMI version

1.4/2.1


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

2


Microphone in

The socket where a microphone is connected to the device.




Headphone outputs

Number of sockets /ports where headphones are connected.

1


Line-out




Line-in




Combo headphone/mic port




S/PDIF out port

S/PDIF (Sony/Philips Digital Interconnect Format) is a digital audio interconnect used in consumer audio equipment over relatively short distances. The signal is transmitted over either a coaxial cable with RCA connectors or a fibre optic cable with TOSLINK connectors.




DC-in jack

The socket/plug where the DC electricity supply connects to the device.




Number of rear USB ports

4


Number of front USB ports

2


Number of front audio ports

1


Fiber NIC port (Flex I/O)




Design


Chassis type

The type of rigid framework onto which is the hosuing for device components.

Mini PC


Colour name

Black


Volume

The amount of a substance contained.

0.84 L


Placement supported

Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.

Horizontal


VESA mounting




Cable lock slot

Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.




Cable lock slot type

Kensington


Product colour

The colour e.g. red, blue, green, black, white.

Black


Housing material

What the casing of the product is made of.

Plastic


Viewing window

Transparent window in the device, which is created to view the progress of performance.




RGB memory lighting




Introduction year
24


Introduction month

July


Country of origin

Country where the device is made. Aka Country of manufacture (COM).

China


Performance


Market positioning

Under which category can the device be positioned in the market, e.g. camera phone.

Business


Powered by

MSI


Motherboard chipset

The chipset connects the microprocessor to the rest of the motherboard.

Intel SoC


Motherboard form factor

Design of the motherboard (ATX, BTX etc).

NUC


Trusted Platform Module (TPM)




Product type

The sub-category of the product.

Mini PC


Trusted Platform Module (TPM) version

2.0


Software


Operating system installed

Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.

Windows 11 Pro


Power


Power supply

The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable.
0 W


Power supply input voltage
0-240 V


Power supply input frequency

The frequency of the electricity, usually measured in Hertz (Hz), which is supplied by the power supply. Mains electricity in many parts of the world is 50Hz.

50-60 Hz


Sustainability


Sustainability certificates

ENERGY STAR, Forest Stewardship Council (FSC), Post-Consumer Recycled Plastic


Weight & dimensions


Width

The measurement or extent of something from side to side.
2.5 mm


Depth

The distance from the front to the back of something.
5.6 mm


Height

The measurement of the product from head to foot or from base to top.

50.1 mm


Weight

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

625 g


Package width

The distance from one side of the packaging to the other.
5 mm


Package depth

The distance from the front to the back of the packaging.

220 mm


Package height

The distance from the top to the bottom of the packaging.

94 mm


Package weight

Weight of the packaged product.

1.45 kg


Packaging content


Mouse included

A mouse is included with this product.




Keyboard included

A keyboard is part of the bundle/set.




Cables included

AC, Power


VESA mount included




Screws included




Display


Display included

This product includes a display.




Other features


TV tuner integrated

Device has an in-built TV tuner.




Built-in microphone

Microphone that is found inside the product.




Locale

English


Warranty period

3 year(s)
