Msi MAG PANO 110R PZ WHITE Mid Tower Case Atx/M-Atx/Mini-Itx MAG PANO 110R PZ WHITE

Product Group:

Cases



Manufacturer:

MSI



SKU:
7231


Product Specifications



Product Name:

MSI MAG PANO 110R PZ White Mid Tower Case (ATX/M-ATX/Mini-ITX)



Web Address:

uk.msi.com



Model Number:

MAG PANO 110R PZ WHITE



EAN:

4711377293198



Package Type:

Retail



Warranty:

2 Years



Case Type:

Mid Tower



Colour:

White



Front USB 5Gbps Port(s) Type-A:

2



Front USB 20Gbps Port(s) Type-A:

1



Front Audio in/out Jack(s):

1



Motherboard Support:

Mini ITX / Micro ATX / ATX



Drive Bay(s):

2 x 2.5-inch
2 x 3.5-inch
2 x 2.5-inch/3.5-inch combo



Pre-installed Fan(s) Rear:

1 x 120mm (ARGB)



Pre-installed Fan(s) Side:

3 x 120mm (ARGB)



Radiator Support:

Top: 120mm / 140mm / 240mm / 280mm / 360mm
Rear: 120mm



Fan Support:

Top: 3 x 120mm / 2 x 140mm
Rear: 1 x 120 mm
Side: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm (Above the power shroud)



Clearances:

Maximum GPU Length: 400mm
Maximum CPU Cooler Height: 160mm
Maximum PSU Length: 200mm



Product Width:

225mm



Product Length:

420mm



Product Height:

485mm



Package Width:

46.4cm



Package Length:

47.5cm



Package Height:

26.2cm



Net Weight:

5.64Kg



Gross Weight:

6.68Kg



Special Features:

270-Degree Display: The chassis features a 270-degree panoramic design with tempered glass, providing an expansive view to showcase detailed components.
Measurements: Supports multiple motherboard sizes, including regular ATX, Micro-ATX, Mini-ITX and back-connect ATX and Micro-ATX, allowing users to customize their PC setup.
Pre-build with Reverse Blades Fan: Pre-installed reverse blade fans on the side ensure an unobstructed display of the ARGB fan-s lighting effects, free from interference by fan frames.
ARGB-Fan Control Board: The 1-to-5 ARGB fan control board supports up to 5 ARGB fans, allowing users to adjust 18 ARGB lighting effects with a single LED switch button
Upgrade Airflow Layout: Supports up to 10 fans, a 360mm radiator on top and a 120mm radiator at rear. The lower chamber, surrounded by vents, further enhances heat dissipation for optimal performance.



Package Contents:

Case
