Msi PRO A620AM-B EVO Socket Am5/A620a/Ddr5/S-Ata 6Gb/S/Micro Atx PRO A620AM-B EVO

Product Group:

Motherboards



Manufacturer:

MSI



SKU:
7664


Product Specifications



Product Name:

MSI PRO A620AM-B EVO (Socket AM5/A620A/DDR5/S-ATA 6Gb/s/Micro ATX)



Web Address:

uk.msi.com



Model Number:

PRO A620AM-B EVO



EAN:

4711377397216



Package Type:

Retail



Warranty:

3 Years



Chipset:

AMD A620A



CPU Interface:

Socket AM5



CPU Support:

https://www.msi.com/Motherboard/PRO-A620AM-B-EVO/support#cpu



RAM Technology:

DDR5 (Dual Channel)



RAM Slots:

2 x 288-pin



RAM Speeds:

Up to DDR5 6800 (O.C.)



Max. Memory Support:
8GB



PCI Express 5.0 x16:

1



PCI Express 4.0 x1:

1



S-ATA 6Gb/s Port(s):

2



M.2 Socket(s):

2 x PCIe Gen 4.0 x4



LAN Speed:

Realtek RTL8125 2.5G LAN



On-Board Audio:


Realtek ALC897 Codec
7.1-Channel High Definition Audio




On-Board Video:

Processor with integrated graphics is required



Back PS/2 Mouse Port:

1



Back PS/2 Keyboard Port:

1



Back USB 2.0 Port(s):

2



Back USB 5Gbps Port(s) Type-A:

4



Back VGA Port(s):

1



Back HDMI Port(s):

1



Back LAN Port(s):

1



Back Audio Jack(s):

3



24-pin ATX Power:

1



8-pin ATX Power:

1



USB 2.0 Header(s):

4



USB 5Gbps Header(s):

3



COM Port Header(s):

1



Front Panel Audio Connector:

1



TPM Header(s):

1



Internal Other Port(s):


1 x Addressable V2 RGB LED connector
1 x RGB LED connector




Form Factor:

Micro ATX



Product Width:

243.84mm



Product Length:

218mm



Package Width:

25.7cm



Package Length:

26cm



Package Height:

5.5cm



Gross Weight:

0.91Kg



Special Features:


Supports AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors.
Supports DDR5 Memory, Dual Channel DDR5 6800+MHz (OC).
Core Boost: With premium layout and digital power design to support more cores and provide better performance.
Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility.
Lightning-Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2.
AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience.
Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.




Package Contents:


Motherboard
QUick Installation Guide
EZ M.2 Clip II Remover
EZ M.2 Clip II
SATA Cable
IO Shield
