Msi PRO B760M-P DDR4 Socket 1700/B760/Ddr4/S-Ata 6Gb/S/Micro Atx PRO B760M-P DDR4

MSI 1700 PRO B760M-P DDR4 M-ATX
SKU: 122852
Product Group:Motherboards
Manufacturer:MSI
SKU:122852
Product Name:MSI PRO B760M-P DDR4 (Socket 1700/B760/DDR4/S-ATA 6Gb/s/Micro ATX)
Web Address:uk.msi.com
Model Number:PRO B760M-P DDR4
EAN:4711377030991
UPC:824142308240
Package Type:Retail
Warranty:3 Years
Chipset:Intel B760
CPU Interface:Socket 1700
CPU Support:https://www.msi.com/Motherboard/PRO-B760M-P-DDR4/support#cpu
RAM Technology:DDR4 (Dual Channel)
RAM Slots:4 x 288-pin
RAM Speeds:Up to DDR4 4800 (O.C.)
Max. Memory Support:128GB
PCI Express 4.0 x16:1
PCI Express 4.0 x1:2
S-ATA 6Gb/s Port(s):4
RAID:Raid 0/1/5/10
M.2 Socket(s):1 x PCIe Gen 4.0 x4
1 x PCIe Gen 4.0 x4/SATA

On-Board LAN:Realtek RTL8111H Gigabit LAN
On-Board Audio:Realtek ALC897 Codec
7.1-Channel High Definition Audio

On-Board Video:Intel processor with integrated graphics is required
Back PS/2 Mouse Port:1
Back PS/2 Keyboard Port:1
Back USB 2.0 Port(s):4
Back USB 3.2 Port(s) Type-A Gen 1:1
Back USB 3.2 Port(s) Type-C Gen 2:1
Back VGA Port(s):1
Back HDMI Port(s):1
Back DisplayPort(s):1
Back LAN Port(s):1
Back Audio Jack(s):3
24-pin ATX Power:1
8-pin ATX Power:1
USB 2.0 Header(s):4
USB 3.2 Header(s) Gen 1:2
Parallel Port Header(s):1
COM Port Header(s):1
TPM Header(s):1
Internal Other Port(s):1 x RGB LED Connector
4 x EZ Debug LED

Form Factor:Micro ATX
Product Width:243.84mm
Product Length:243.84mm
Package Width:27.5cm
Package Length:30cm
Package Height:5.3cm
Gross Weight:0.87Kg
Special Features:Lightning Gen4 Solution: The latest Gen4 PCI-E and M.2 solution with up to 64GB/s bandwidth for maximum transfer speed.
USB 3.2 Gen 2 Type-C: Synergize with a MSI motherboard through bridging with a USB 3.2 Gen 2 Type-C port for convenient access.
PCI-E Steel Armor: Protecting VGA cards against bending and EMI.
EZ Debug LED: Easiest way to troubleshoot.
Frozr AI Cooling: Detect CPU and GPU temperatures and automatically adjust system fan duty to a proper value.
Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
Audio Boost: Reward your ears with studio grade sound quality for the most immersive audio experience.

Package Contents:Motherboard
Quick Installation Guide
2 x M.2 Screw / Standoff Sets
SATA Cable
IO Shield
