Newland Wd4 Ring Scanner. Type: Wearable Bar Code Reader Scanner Type: 1D/2D Sen WD4-BS20-SR

Newland WD4 Ring Scanner. Type: Wearable bar code reader, Scanner type: 1D/2D, Sensor type: LED. Connectivity technology: Wireless, Standard interfaces: Bluetooth, Wireless range: 40 m. Product colour: Black, International Protection (IP) code: IP42, Protection features: Drop resistant, Electrostatic Discharge (ESD) protection. Power source type: Battery, Battery technology: Lithium-Ion (Li-Ion), Battery capacity: 670 mAh. Weight: 48 g, Width: 52.5 mm, Depth: 38 mm With its lightweight design and seamless pairing to your host device, the WD4 Ring Scanner is your perfect companion. Designed to comfortably sit on your finger, the ring shape of the WD4 allows for a secure fit, ensuring it stays in place even during rigorous tasks. Whether you're carrying boxes or engaged in other daily activities, scan hands-free and multitask with the WD4 Ring Scanner! #Gearup with WD4 Ring Scanner Do not waste time on putting the scanner away while carrying or picking up boxes, and easily scan with a light press of your thumb. With WD4's comfortable fit and long-lasting battery, you are ready for the full shift of uninterrupted workflow and minimal fatigue!
Interfaces/Ports

Host InterfaceUSB

Memory

Flash Memory1 MB

Power Description

Power Supply IncludedYes

Physical Characteristics

Weight (Approximate)48 g
Length52.5 mm
Height44.2 mm
Width38 mm

Technical Information

Barcode Symbology Supported
1D:Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Standard 25, Codabar, Industrial 25, Code39, Code 93, Code 11, Plessey, MSI-Plessey, GS1-DataBarTM(RSS), Matrix 2 of 5, Interleaved 2 of 5, ITF-6, ITF-14

2D:-?? PDF417, QR Code, Data Matrix, Aztec, Micro PDF, Micro QR

Connectivity TechnologyWireless
FeaturesBeep
Notification LED
Vibration
Drop SpecificationDrop 1.2m




Depth of FieldEAN 13 (13mil): 55-280 mm
Code 39 (5mil): 55-145 mm
PDF417 (6.7mil): 40-130 mm
DataMatrix (10mil): 40-140 mm
QR (15mil): 30-195 mm

Image Sensor TypeCMOS
Illumination TypeLED
Illumination ColorWhite
Cable Type IncludedUSB
Scanning Capability1D
2D
Reading Angle (Skew)60??
Reading Angle (Pitch)60??
Reading Angle (Roll)360??
Minimum Print Contrast20%
Air Electrostatic Discharge (+/-)12kV
Contact Electrostatic Discharge (+/-)8kV
Image Sensor Resolution640 x 480


Battery Information

Battery ChemistryLithium Ion (Li-Ion)
Battery Capacity670 mAh
Battery IncludedYes
Maximum Battery Run Time8 Hour
Maximum Battery Recharge Time2 Hour

General Information

Product TypeBarcode Scanner
Manufacturer Part NumberWD4BS20SR
newland-id
ManufacturerNewland
Product NameWD4 Ring Scanner
Brand NameNewland

Miscellaneous

Application/UsageIndustrial
Logistics
Retail
Warehouse
Package ContentsWD4 Ring Scanner
USB-A to Magnetic connector cable

Platform SupportedAndroid
iOS
Smartphone
PC
Mac
Software Supported
EasyConnect

Environmentally FriendlyYes
Ingress Protection (IP) RatingIP42
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
