Noctua NF-A20-FLX Nf-A20 Flx Computer Case Fan NF-A20-FLX

The NF-A20 is a highly optimised, premium quality quiet 200mm fan. Featuring an AAO (Advanced Acoustic Optimisation) standard frame as well as sophisticated aerodynamic design measures such as Flow Acceleration Channels, the NF-A20 brings the renowned quiet cooling performance of Noctua�s award-winning A-series to the increasingly popular 20cm form factor. The FLX version provides 800/550rpm speed settings via the supplied Low-Noise Adaptor in order to provide full flexibility in fine-tuning the fan for maximum ventilation performance or near-silent operation. Its superb running smoothness, reference-class SSO2 bearing and Noctua�s trusted premium quality make the NF-A20 an elite choice for the highest demands.

Design



Fan connector



3-pin


Number of fins



1


Product colour



Beige, Brown


Logistics data



Harmonized System (HS) code



84733080


Package dimensions



Gross Weight (Package, kg)



0.26 kg


Packaging content



Low-noise adaptor (LNA)



Yes


Screws included



Yes


Performance



Airflow



146.9 m�/hr


Airflow with LNA (max)



100.8 m�/hr


Fan diameter



20 cm


Maximum air pressure



1.08 mmH2O


Mean time between failures (MTBF)



150000 Hour


Noise level (high speed)



18.1 dB


Noise level with LNA (max)



10.7 dB


Rotational speed (max)



800 RPM


Rotational speed with LNA (max)



550 RPM


Suitable location



Computer case


Type



Fan


Power



Power consumption (typical)



0.96 Watt


Rated current



0.08 A


Voltage



12 V


Product dimensions



Net Weight (Product, kg)



0.2 kg


Product Depth



3 cm


Product Height



20 cm


Product Width



20 cm


Vendor information



Brand Name


Noctua


Warranty



1 Year(s)
