Planet
Planet POE-E301 1-Port 802.3bt to 1-Port POE-E301
(No reviews yet)
Write a Review
- UPC:
- 4711605287340
- MPN:
- POE-E301
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Long Distance 802.3bt PoE++ and Gigabit Data Extension Solution
PLANET POE-E301 is a simple extender that extends both the Gigabit Ethernet Data and IEEE 802.3bt/802.3at/802.3af Power over Ethernet transmission distance over the standard 100m (328 ft.) Cat. 5/5e/6 UTP cable to 200m, 300m, 400m and the maximum 400m. The POE-E301 can obtain a maximum of 95-watt PoE power from 802.3bt PoE++ input port and the output port can supply a maximum of 65-watt power, providing a simple solution to achieve more wide-coverage network applications without requiring an external power adapter.
No matter how many PoE supported networking devices such as PoE IP cameras, PoE wireless access points and PoE IP phones are deployed, they are easily installed without the need of having an additional electrical outlet. However, limited by the UTP cabling, only up to 100 meters (328 ft.) of cable is used. Thus, the POE-E301 is designed as the extender to transmit both Gigabit Ethernet data and 802.3bt PoE++ power over another distance of 100m. By daisy-chaining multiple POE-E301s, distance can be tripled or quadrupled to meet your requirements.
With its ability to provide 802.3bt PoE++ and Gigabit Ethernet data extension, the POE-E301 is an ideal networking solution for service providers, campuses and public areas. It enables you to centrally manage the power easily, efficiently and cost-effectively no matter how remote the location is.
Plug and Play, and Easy Cabling Installation
The POE-E301 Gigabit 802.3af/at/bt PoE Extender is quite easy to be installed by the simple plug and play configuration. It is used between a power source equipment (PSE) and a powered device (PD). The POE-E301 injects power to the PD without affecting the data transmission performance. It offers a cost-effective and quick solution to double the standard range of PoE from 100 to 200 meters. The POE-E301 Compact 2-Port 802.3af/at/bt PoE Extender, suitable for use, features 2 1000Mbps auto-negotiation ports, of which the "PoE IN" port functions as PoE (Data and Power) input and the "PoE OUT" port on the other side functions as PoE (Data and Power) output. The "PoE OUT" port is also the power injector to transmit DC voltage via the Cat. 5/5e/6 cable and transfer data and power simultaneously between the PSE and a PD.
Learn more: https://www.planet.com.tw/en/product/poe-e301
Design
Certification
FCC Part 15 Class A, CE
Housing material
Metal
LED indicators
Y, Yes
Product colour
Blue
Operational conditions
Operating relative humidity (H-H)
5 - 95 %
Operating temperature (T-T)
0 - 50 °C
Storage relative humidity (H-H)
5 - 95 %
Storage temperature (T-T)
-40 - 85 °C
Package dimensions
Gross Weight (Package, kg)
0.25 kg
Performance
Maximum transfer distance
400 m
Type
Network transmitter & receiver
Ports & interfaces
RJ-45 ports quantity (receiver)
1
RJ-45 ports quantity (transmitter)
1
Power
Power over Ethernet (PoE)
Yes
Product dimensions
Net Weight (Product, kg)
0.25 kg
Product Depth
7 cm
Product Height
2.6 cm
Product Width
9.4 cm
Vendor information
Brand Name
Planet
Warranty
3 Year(s)
