Planet SW-504 5-Port 10/100Base-TX Ethernet SW-504
(No reviews yet)
Write a Review
- UPC:
- 4711213684425
- MPN:
- SW-504
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
With concepts of "Easy to install and use", "Compact-sized design", and "Simple troubleshooting", PLANET SW-504 provides cost-conscious business and home users with the foundation of an integrated system of small-office / home-office networking. The SW-504 is a fancy-shaped plastic model, which is just right for your network of 10 to 50 users.
The SW-504 Desktop Fast Ethernet Switch is simple and cost-effective, and offers highly reliable network . And it is the ideal device for bridging Ethernet and Fast Ethernet workgroups or networks. Therefore, PLANET SW-504 switch will be recognized as one of the most important building blocks for today�s networking technology.
To segment the network and ease the network traffic, the 5-port 10/100Mbps is useful for the SOHO switched networks as the friendly network backbone. With LED indicators, the network status can be monitored at a glance.
Data transmission
MAC address table
2000 entries
Store-and-forward
Yes
Switching capacity
1 Gbit/s
Throughput
0.744 Mpps
Design
Certification
FCC Part 15 Class B, CE
LED indicators
Y, Yes
Product colour
White
Logistics data
Harmonized System (HS) code
85176990
Network
10G support
No
Auto MDI/MDI-X
Yes
Networking standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Operational conditions
Heat dissipation
12 BTU/h
Operating relative humidity (H-H)
5 - 90 %
Operating temperature (T-T)
0 - 50 �C
Storage relative humidity (H-H)
5 - 90 %
Storage temperature (T-T)
-20 - 70 �C
Package dimensions
Depth (package,cm)
45 cm
Gross Weight (Package, kg)
0.43 kg
Height (package,cm)
23 cm
Width (package,cm)
44 cm
Packaging data
AC adapter included
Yes
Performance
Harmonized System (HS) code
85176990
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Power
AC input voltage
5 V
DC input voltage
5 V
Input current
1 A
Power consumption (typical)
3.7 Watt
Power source
DC
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Product dimensions
Net Weight (Product, kg)
0.13 kg
Product Depth
10 cm
Product Height
2.9 cm
Product Width
16.8 cm
Vendor information
Brand Name
Planet
Warranty
3 Year(s)
