QNAP QVP-21C 2-bay high-performance NVR QVP-21C
- UPC:
- 4711103084366
- MPN:
- QVP-21C
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The QVP-21C QVR Pro appliance is a tower-based network surveillance server with an Intel� Celeron� quad-core processor that supports eight free IP camera channels and up to sixteen IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-21C fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.
Supports ONVIF cameras
Compatible with thousands of cameras from over 190 brands and ONVIF standards.
Long-term model
The QVP-21C will be available and supported by QNAP for an extended period, up to 2029.
Dual HDMI� outputs
Play and switch between multi-channel real-time 4K videos on two monitors with extended display.
High-performance NVR
Boost your surveillance data transmission efficiency with dual-port 2.5GbE, a USB 3.2 Gen2 10Gbps port, and 8GB RAM.
RAID protection
Unlike traditional DVR and NVR, the QVP-21C protects your data from drive failure with RAID.
Lightweight AI surveillance applications
QVP-21C incorporates QNAP smart surveillance applications and supports Intel� OpenVINO� AI engine and Edge TPU expansion via M.2 SSD slots to boost facial recognition performance in QVR Face.
QVP-21C vs. other NAS-based surveillance systems. What�s the difference?
In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-21C QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-21C also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-21C to start the installation process.
Design
Chassis type
Tower
Cooling type
Active
Fan diameter
7 cm
LED indicators
Y, Yes
Number of fans
1 fan(s)
Product colour
Black
Memory
Flash memory
4000 MB
Internal memory
8 GB
Internal memory type
DDR4
Maximum RAM supported
16 GB
Memory clock speed
3200 MHz
Memory form factor
SO-DIMM
Memory slots
2
Network
DHCP server
Yes
Ethernet LAN
Yes
Ethernet LAN data rates
2500
Operational conditions
Operating relative humidity (H-H)
5 - 95 %
Operating temperature (T-T)
0 - 40 �C
Package dimensions
Gross Weight (Package, kg)
1.57 kg
Performance
Backup function
Yes
Buzzer
Yes
Device class
Home & Home Office
Noise level
15.4 dB
On/off switch
Yes
Reset button
Yes
S.M.A.R.T. support
Yes
Snapshot
Yes
Type
Storage server
Video input channels
8 channels
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
HDMI ports quantity
2
HDMI version
1.4b
USB 2.0 ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB port
Yes
Power
AC input voltage
100 - 240 V
Power consumption (typical)
60 Watt
Processor
On-board graphics card model
Intel� UHD Graphics
Processor boost frequency
2.6 GHz
Processor cores
4
Processor family
Intel� Celeron�
Processor manufacturer
Intel
Processor model
J6412
Product dimensions
Net Weight (Product, kg)
2.57 kg
Product Depth
22.05 cm
Product Height
16.92 cm
Product Width
10.2 cm
Software
Operating system installed
QVR Pro
Storage
Hot-swap drive bays
Yes
Installed storage drive type
No
Number of storage drives supported
2
Online RAID migration
Yes
RAID levels
0, 1, 5+HS, 5, 6, 10+HS, 10, JBOD
RAID support
Yes
Storage drive sizes supported
2.5, 3.5, M.2
Storage drives installed
No
Supported file systems
ext4
Supported storage drive interfaces
M.2, Serial ATA III
Supported storage drive types
HDD & SSD
Vendor information
Brand Name
QNAP
Warranty
3 Year(s)
