Ricoh FI-7900 304.8 x 431.8 mm 600 x 600 DPI 24 bit 8 bit 1 bit 140 ppm PA03800-B001

The fi-7900 achieves scanning speeds of 140 ppm/280 ipm (A4 landscape, color, 200/300 dpi), is capable of scanning up to as many as 120,000 sheets a day, and is highly optimized for centralized scanning.

The scanner is designed with operator usability as its first priority. It provides high quality technology for reliable scanning, a user-friendly design inherited from our high-end scanners, as well as enhanced image processing functions. Users can enjoy comfortable scanning while improving their work efficiency significantly.

Features


Automatic Separation Control function and Skew Reducer to ensure stable feeding


Paper Protect function to prevent documents from being damaged


Stacking Control function and Elevator Stacker for easy paper collection from the stacker


Manual Feed Mode to scan various types of documents


Environment-friendly product certified with ENERGY STAR Version 3


Low profile design with operation panel and LCD for comfortable scanning


Cleaning Mode for easy maintenance



Scanning


Colour scanning

Yes


ADF scan speed (b/w, A4)
0 ppm


Optical scanning resolution

600 x 600 DPI


Black/white scanning colour modes

Grayscale, Monochrome


Duplex scanning

Yes


Maximum scan size

304.8 x 431.8 mm


Duplex ADF scan speed (b/w, A4)

280 ipm


Output monochrome depth

1 bit


ADF scan speed (colour, A4)
0 ppm


Duplex ADF scan speed (colour, A4)

210 ipm


Output greyscale depth

8 bit


Output colour depth

24 bit



Input capacity


Auto document feeder (ADF) input capacity

500 sheets



Other features


Background colours

Black, White


Selectable background colour

Yes


Compliance certificates

RoHS



Ports & interfaces


Standard interfaces

USB 2.0


USB connector type

USB Type-B


USB version

2.0


Socket connector type

C13


USB port

Yes



System requirements


Windows operating systems supported

Windows 10, Windows 10 x64, Windows 7, Windows 8



Design


Scanner type

ADF + Manual feed scanner


Built-in display

Yes


Product colour

Black, Grey



Paper handling


Maximum ISO A-series paper size

A3


Letter

Yes


Maximum scan length

5.59 m


Long-paper mode

Yes


Minimum scan area (ADF)

52 x 74 mm


Legal

Yes


Multi feed detection

Yes


ISO A-series sizes (A0???A9)

A3, A4, A5, A6


ISO B-series sizes (B0???B9)

B5, B6


Auto Document Feeder (ADF) media weight
- 209 g/m



Weight & dimensions


Height

310 mm


Width

460 mm


Depth

430 mm


Weight

32 kg



Packaging content


Cables included

AC


Drivers included

Yes



Logistics data


Wood packaging weight

0 g


Pallet height (sea)
7 cm


Products per pallet (air)

4 pc(s)


Plastic packaging weight
g


Paper packaging weight

2.4 kg


Metal packaging weight

0 g


Cardboard packaging weight

1.2 kg


Polystyrene (EPS/EPP) packaging weight
0 g


Harmonized System (HS) code

8471607000


Pallet height (air)
9 cm


Pallet gross length

70 cm


Products per pallet (sea)

6 pc(s)


Glass packaging weight

0 g


Country of origin

Japan


Foil packaging weight
g


Pallet gross width
0 cm



Sustainability


Sustainability certificates

ENERGY STAR



Operational conditions


Operating temperature (T-T)

5 - 35 C


Operating relative humidity (H-H)
- 80



Performance


Light source

White LED (4x)


Sensor type

Dual CCD


Ultrasonic double sheet detection

Yes


Daily duty cycle (max)
0000 pages


Scan drivers

ISIS, TWAIN, WIA


Scanner error detection

Yes



Power


Power consumption (off)

0.3 W


Sleep mode

Yes


Power consumption (sleep)

3.2 W


Power consumption (typical)
0 W


Power supply type

AC



Packaging data


Package height

618 mm


Quantity per pack

1 pc(s)


Package depth

642 mm


Package width

548 mm


Package weight

39 kg
