Samsung OH46B-S Digital signage flat panel 116.8 cm 46 VA 3500 cd/m? Full HD Bla LH46OHBESGBXEN

Specs




Display


Panel type

VA


Display diagonal

Size of the display for this product, measured diagonally, usually in inches.
6.8 cm (46")


Display technology

The technology used in the display e.g. plasma, LED.

LCD


Display resolution

The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width - height, with the units in pixels: for example, "1024 - 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
20 x 1080 pixels


Display brightness

Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'.

3500 cd/m-


HD type

Type of supported High Definition (e.g. Full HD, 4K Ultra HD).

Full HD


Touchscreen

A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.




Response time

The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)

6 ms


Contrast ratio (typical)

The difference in light intensity between the brightest white and the darkest black.

6000:1


Dynamic contrast ratio marketing name

Mega Contrast


Viewing angle, horizontal

Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
8-


Viewing angle, vertical

Maximum vertical angle at which a display can be viewed with acceptable visual performance.
8-


Pixel pitch

This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image.

0.53 x 0.53 mm


Horizontal scan range
- 135 kHz


Vertical scan range

24 - 75 Hz


Glass thickness

5 mm


Glass film

AG/AR Film


RGB colour space

NTSC


Colour gamut

72%


Ports & interfaces


HDMI ports quantity

The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.

2


HDMI version

2.0


DVI port

Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.




USB port

The device features a socket into which a USB cable can be plugged.




USB ports quantity

1


Ethernet LAN (RJ-45) ports

Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

2


Audio (L/R) out

The two sockets (ports) for transmitting left audio signal (white cable) and right audio signal (red cable).

1


RS-232 interface




Audio


Built-in speaker(s)

The device contains speaker(s) to produce sound.




Design


Product design

The creation of a plan or convention for the construction of an object or a system.

Digital signage flat panel


Orientation

Horizontal/Vertical


Product colour

The colour e.g. red, blue, green, black, white.

Black


Screen shape

Flat


VESA mounting




Panel mounting interface

The product can be used wih VESA mounting interfaces.

995 x 500 mm



Design


Bezel width (bottom)

2.49 cm


Bezel width (side)

2.49 cm


Bezel width (top)

2.49 cm


Bezel colour

Black


Performance


Purpose

What the product is used for.

Universal


Operating hours (hours/days)

24/7


HDCP

High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.




HDCP version

2.2


Power


Power consumption (typical)

Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.

430 W


Power consumption (sleep)

0.5 W


AC input voltage

The voltage of the AC electricity that is inputted into the product.
0 - 240 V


AC input frequency

50 - 60 Hz


Computer system


Computer system




Computer system type

System on Chip (SoC)


Built-in processor

Whether or not a processor is built into the device.




Operating system installed

Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.

Tizen 6.5


Weight & dimensions


Display width
69 mm


Display depth

85 mm


Display height

623.6 mm


Display weight

36 kg


Packaging data


Package width

The distance from one side of the packaging to the other.
56 mm


Package depth

The distance from the front to the back of the packaging.
0 mm


Package height

The distance from the top to the bottom of the packaging.

713 mm


Package weight

Weight of the packaged product.

40.5 kg


Operational conditions


Operating temperature (T-T)

The minimum and maximum temperatures at which the product can be safely operated.

-30 - 50 -C


Operating relative humidity (H-H)
- 80%


Certificates


Certification

Class A 60950-1, 62368-1


Network


Ethernet LAN

An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.




Wi-Fi

Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.




Other features


Flash memory

8000 MB


Glass protection
