Startech 25m 82ft LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable 50/125�m LOMM 450FBLCLC25

LSZH Jacket | Aramid Fiber Sheath | Ideal for SANs, data servers, SFP+The LC to LC Multimode Duplex Fiber Optic Patch cable facilitates reliable connectivity across 40 and 100 Gigabit networks.Engineered for Optimal PerformanceWith laser-optimized multimode fiber (LOMMF), the OM4 fiber patch cable is ideal for 850 nm and 1350 nm Vertical Cavity Surface Emitting Laser (VCSEL) and LED sources. Precision-manufactured ceramic ferrules ensure correct fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics over older PC polishing techniques which may negatively affect performance.Wide CompatibilityThis multimode 50/125�m fiber optic patch cord is backward compatible with OM3 and 1/10/40 Gbps networks, ensuring a reliable connection with legacy fiber environments.Flame ResistantHoused in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to high heat or in the event of a fire. It enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where building codes are a consideration.Each OM4 fiber cable is also individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.The StarTech.com Advantage

Features


OM4 FIBER CABLE: OM4 Laser-Optimized Multimode Fiber Cable is immune to EMI and supports up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors enable quick visual identification of polarity and conversion to simplex cabling


QUALITY CONSTRUCTION: LC/LC connectors with UPC polished ends significantly improves return loss over PC polish; Robust molded connector strain reliefs minimizes wear from bending; Protective Aramid fiber for increased tensile strength


SAFETY AND RELIABILITY: Individually tested for signal integrity; LSZH (low smoke zero halogen) jacket does not emit toxic fumes if combusted; Safe for enclosed/poorly ventilated spaces; Attenuation value under 2.3dB/km meets or exceeds industry standards


WIDE COMPATIBILITY: OM4 LC/LC multimode cable supports 1/10/40/100 Gbps networks; Backward compatible with OM3; For high-density network applications such as SANs, data servers, fiber switches, SFP+, QSFP+, and QSFP28 transceivers


SPECS: 25m (82ft); Color: Aqua (OM4); LC/LC UPC; 50/125�m Core/Cladding; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: 2000MHz�km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life



Weight & dimensions


Bending radius

6 cm


Cable diameter

2.9 mm



Logistics data


Master (outer) case width

410 mm


Master (outer) case height

450 mm


Products per master (outer) case

32 pc(s)


Master (outer) case length

410 mm



Technical details


Sustainability compliance

Yes


Sustainability certificates

CE, RoHS



Features


Fiber mode structure

Multi-mode


Core diameter

50 �m


Cable length

25 m


Product colour

Aqua colour


Wavelengths supported

850,1300 nm


Connector 2

LC


Connector 1

LC


Connector 1 gender

Male


Connector 2 gender

Male


Cladding diameter

125 �m


Fibre optic type

OM4


Data transfer rate

100 Gbit/s


Full duplex

Yes


Jacket material

Low smoke zero halogen (LSZH)



Operational conditions


Operating temperature (T-T)

-20 - 60 �C


Storage temperature (T-T)

-20 - 60 �C



Packaging data


Package height

51 mm


Quantity per pack

1 pc(s)


Package depth

255 mm


Package width

330 mm


Package weight

342 g
