Startech 8M 26.2Ft Lc Upc Om4 Multimode Fiber Optic Cable W/Push Pull Tabs 50/12 450FBLCLC8PP

StarTech.com 8m (26.2ft) LC (UPC) OM4 Multimode Fiber Optic Cable w/Push Pull Tabs, 50/125?-m, 100G, Low Insertion Loss, LSZH Jumper Cord - 8m (26.2ft) OM4 LOMMF LC/LC-UPC Fiber Cable w/Push Pull Tabs; 10/40/100Gbps Full Duplex; 50/125?-m Bend-Insenitive Fiber; BW: 4700MHz.km at 850nm; Bend Radius: 6cm (loaded)/3cm (unloaded); OD: 3mm; Jacket: LSZH; Temp Range: -20 to 60C (-4 to 140F) LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable enables 40/100G network connections. The push-pull tabs on each connector ensure quick connection and removal, facilitating accurate installation in high connection density environments. The bend-insensitive fiber and molded strain reliefs support cable runs requiring micro/macro bends while maintaining low attenuation. The retractable strain-relief housings enable toolless in-field polarity swapping. Color-coded LC-Duplex connectors ensure error-free polarity configuration. Engineered for Optimal Performance Precision-manufactured ceramic ferrules ensure accurate fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics. The Laser-Optimized Multi-Mode Fiber (LOMMF) OM4 fiber patch cable is ideal for 850nm and 1300nm Vertical-Cavity Surface-Emitting Laser (VCSEL) and LED sources. Compatibility This multimode 50/125?-m fiber optic patch cord is backward compatible with OM3 and 1/10/40G networks, ensuring a reliable connection in legacy fiber environments. LSZH Cable Jacket Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered. Each OM4 fiber cable is also individually tested for insertion loss performance that meets or exceeds the TIA/EIA-568 industry standard, for guaranteed compatibility and 100% reliability.
Physical Characteristics

Product ColorAqua
Color FamilyGreen

Technical Information

Cable Length8 m
Data Transfer Rate100 Gbit/s
Device SupportedSwitch
Server
Module
Network Device
Jacket TypeLSZH
FeaturesMolded
Strain Relief
UPC Polished Connector
Bendable
Flame Retardant
Bend Insensitive
Cable CharacteristicPatch Cable
Cable TypeFibre Optic
Connector Type on First EndLC/UPC Network - Male
Connector Type on Second EndLC/UPC Network - Male
Fiber Optic ModeMulti-mode
Fiber TypeDuplex
Connector on First End Details2 x LC/UPC Network - Male
Connector Gender on First EndMale
Connector Gender on Second EndMale
Fiber CategoryOM4


Miscellaneous

REACH Declaration URLhttps://media.startech.com/cms/pdfs/450fblclc8pp_rohs.pdf
EU RoHS Declaration URLhttps://media.startech.com/cms/pdfs/450fblclc8pp_rohs.pdf
End of Life Manual AvailabilityYes
REACH free of SVHCYes
WEEE Statementhttps://media.startech.com/cms/pdfs/450fblclc8pp_weee.pdf

General Information

Product TypeNetwork Cable
Manufacturer Part Number450FBLCLC8PP
Manufacturer Website Addresshttp://www.startech.com/uk
Packaged Quantity1
ManufacturerStarTech.com
Product NameFiber Optic Duplex Patch Network Cable
Brand NameStarTech.com
