StarTech.com Fiber Media Converter Gigabit 1000Mbps MM Fibre LC 550m ET91000LC2

Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multimode LC fiber

The ET91000LC2 1000 Mbps Gigabit Multimode Fiber Media Converter (LC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).

A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, this GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet-to-fiber solution, the Ethernet to LC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.

For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U), as well as a replaceable SFP slot.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Link loss forwarding, remote status monitoring ensures maximum up-time
- Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility
- Rugged steel casing for durability in harsh environments

Features


Supports standalone operation, or installation into the ETCHS2U Rackmount Chassis


SFP can be removed from the unit, for replacement or swapping to a different specification


Cost-effective way to extend/bridge networks using fiber cabling


Advanced features include Link-loss forwarding, remote monitor status, two frame lengths


Maximum Fiber Cable length of 550m


Supports full or half-duplex operation


Easy to use and install



Other features


Full duplex

Yes


Dimensions (WxDxH)

95 x 160 x 20 mm



Ports & interfaces


Fiber ports quantity

1


Ethernet LAN (RJ-45) ports

1


Fiber optic connector

LC


DC-in jack

Yes


Connectivity technology

Wired



Management features


Plug and Play

Yes



Design


Internal

No


Product colour

Black


Certification

CE, FCC



Weight & dimensions


Weight

620 g



Packaging content


Manual

Yes



Logistics data


Harmonized System (HS) code

85176990



Technical details


Sustainability certificates

RoHS



Network


Converter output interface
00Base-LX, 1000Base-SX


Converter input interface
00Base-T


Duplex system

Full, Half


Maximum data transfer rate
00 Mbit/s


Auto MDI/MDI-X

Yes


Ethernet interface type

Gigabit Ethernet


Ethernet LAN data rates
00 Mbit/s



Operational conditions


Operating temperature (T-T)

0 - 60 -C


Operating relative humidity (H-H)
- 90


Storage temperature (T-T)

-10 - 70 -C



Performance


Fiber mode structure

Multi-mode


Mean time between failures (MTBF)

65000 h


Maximum transfer distance

550 m


Wavelength

850 nm



Power


External power adapter

Yes


Output voltage
V


Power consumption (typical)

4 W


Output current

1 A



Packaging data


Package height

89 mm


Package depth
8 mm


Package width
6 mm


Package weight

774 g
