StarTech.com PEX40GQSFDPI DUAL-PORT QSFP+ SERVER NIC PEX40GQSFDPI

Add two high-bandwidth 40 Gigabit fiber Ethernet ports to your server or workstation, using the QSFP+ transceiver of your choice

Get fast, high-bandwidth connectivity with this dual-port QSFP+ Network Interface Card. It adds two open QSFP+ slots to your server or workstation. The 40G NIC features an Intel controller and provides redundant network links with reliable performance. It�s ideal for high-demand database servers, virtualized servers and agile data centers that require infrastructure updates with no downtime.

Increase your network speed

This dual port QSFP+ server NIC card lets you take advantage of the speed and stability of a 40 Gigabit network, with data transfers of up to 40Gbps.

Add redundant connections in zero-downtime environments

With two QSFP+ ports, the PCIe NIC helps to prevent network downtime by adding fault-tolerant connections using two modules, to provide high-bandwidth network links to your mission-critical servers or workstations.

Add scalable network connections

With its open QSFP+ slots, the network interface card supports QSFP+ transceiver modules and is compatible with multimode and single-mode fiber, providing a scalable networking solution.

Enhance your network capabilities

The 40G NIC uses an Intel XL710 chipset providing reliable connectivity and convergent network features. It offers many advanced features including Intel Virtualization Technology for Connectivity.

The PEX40GQSFDPI is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

- DUAL QSFP+ NETWORK CARD: Two port 40GbE converged network adapter for redundancy or can be aggregated for demanding applications; Data Center Bridging (DCB), virtualization & iSCSI offload support
- TECH SPECS: 2x 40 Gbps Open QSFP+ Ports
- MSA Compliant

Design



Chipset



Intel - XL710-BM2


Component for



PC/Server


Internal



Yes


LED indicators



Activity, Link


Product colour



Black


Logistics data



Harmonized System (HS) code



85176990


Master (outer) case height



32 cm


Master (outer) case length



44 cm


Master (outer) case width



42 cm


Products per master (outer) case



40 pc(s)


Network



Ethernet LAN



No


Fiber ethernet cabling technology



40GBASE-LR4, 40GBASE-SR4


Full duplex



Yes


Jumbo frames



9000


Jumbo frames support



Yes


Maximum data transfer rate



40000 Mbit/s


Networking standards



IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3ba, IEEE 802.3x


VLAN tagging



Yes


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 57 �C


Storage temperature (T-T)



-20 - 85 �C


Other features



Flow control support



Yes


Quick start guide



Yes


Package dimensions



Depth (package,cm)



20.7 cm


Gross Weight (Package, kg)



0.212 kg


Height (package,cm)



4 cm


Width (package,cm)



14.5 cm


Packaging data



Low-profile bracket



Yes


Ports & interfaces



Connectivity technology



Wired


Fiber optic connector



QSFP+


Fiber ports quantity



2


Host interface



PCI Express


Interface



Fiber


PCI version



3.0


Product dimensions



Net Weight (Product, kg)



0.127 kg


Product Depth



18.1 cm


Product Height



2.1 cm


Product Width



12.1 cm


Sustainability



Sustainability certificates



CE, RoHS


Sustainability compliance



Yes


System requirements



Linux operating systems supported



Yes


Server operating systems supported



Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019


Windows operating systems supported



Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
